Balluff BOW001J Optical Window Sensor 80 × 80 mm Infrared PNP
- Regular price
- $1,602.00
- Sale price
- $1,602.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: BOW001J
Description
The Balluff BOW001J is an infrared optical window sensor designed to detect falling objects and small parts within an 80 × 80 mm active window. It uses a dynamic PNP normally open output and through-beam sensing technology to provide reliable object detection in industrial automation applications.
Technical Specifications
|
Condition |
New/Never Used Surplus |
|
Brand |
Balluff |
|
Category |
Automation Control Components |
|
Part Number |
BOW001J |
|
Subcategory |
Photoelectric Sensors |
|
Product Type |
Optical Window Sensor |
|
Sensing Principle |
Through-beam |
|
Light Type |
Infrared |
|
Wavelength |
880 nm |
|
Active Window |
80 × 80 mm |
|
Minimum Detectable Part |
1.0 mm, dynamic |
|
Switching Output |
PNP dynamic, normally open (NO) |
|
Operating Voltage |
10–30 VDC |
|
Rated Operating Voltage |
24 VDC |
|
Rated Operating Current |
200 mA |
|
Switching Frequency |
100 Hz, dynamic |
|
Connection |
M8 × 1 male connector, 3-pin |
|
Housing Material |
Black anodized aluminum |
|
Sensing Surface Material |
PMMA |
|
Protection Rating |
IP67 |
|
Ambient Temperature |
-10 to 55 °C |
|
Dimensions |
18 × 130 × 140 mm |
|
Weight |
0.96 lb |
Information About BOW001J
The BOW001J belongs to Balluff’s Series A optical window sensor range and features a frame-style design. Its black anodized aluminum housing and PMMA sensing surface provide a durable construction for industrial environments. The sensor operates on a 10–30 VDC supply and connects through a 3-pin M8 male connector. It supports dynamic detection of parts as small as 1.0 mm and has an IP67 protection rating.
Key Features:
-
Optical Window Detection: Detects objects passing through an 80 × 80 mm active window.
-
Infrared Sensing: Uses infrared light with a through-beam optical operating principle.
-
Dynamic PNP Output: Provides a normally open switching output for object detection.
-
Small-Part Detection: Supports detection of parts as small as 1.0 mm in dynamic operation.
-
Industrial Construction: Features a black anodized aluminum housing and PMMA sensing surface.
-
Electrical Connection: Uses a 3-pin M8 × 1 male connector.
-
Operating Voltage: Supports a 10–30 VDC supply voltage.
-
Environmental Protection: IP67-rated enclosure helps protect against dust and water ingress.
The BOW001J delivers the reliability and precision required for small-part detection, material handling, and industrial automation systems.
