Banner Engineering SLSR30-300Q8 EZ-SCREEN 300mm Safety Light Curtain Receiver
- Regular price
- $999.00
- Sale price
- $999.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: SLSR30-300Q8
Description
The Banner Engineering SLSR30-300Q8 is an EZ-SCREEN SLS Series safety light curtain receiver designed for machine guarding and personnel protection. It provides a 300 mm defined protective area with 30 mm resolution and an operating range of up to 18 m. The receiver uses an 8-pin M12 integral quick-disconnect connection and operates from a 24 VDC supply.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Banner Engineering |
| Category | Safety & Machine Controls |
| Part Number | SLSR30-300Q8 |
| Subcategory | Safety Light Curtains |
| Series | EZ-SCREEN SLS / 14/30 Series |
| System Type | Receiver |
| Resolution | 30 mm |
| Defined Area Height | 300 mm |
| Operating Distance | 0.1–18 m |
| Maximum Operating Range | 18 m (60 ft) |
| Safety Level | Type 4 |
| Performance Level | PL e |
| SIL Rating | SIL 3 / CL 3 |
| Supply Voltage | 24 VDC |
| Number of Pins | 8 |
| Response Time | 11 ms |
| IP Rating | IP65 |
| Housing Material | Aluminum, Zinc, Acrylic |
| Housing Finish | Black Polyester |
| Operating Temperature | 0°C to +55°C |
| Relative Humidity | 95% |
| OSSD Rating | 24 VDC at 0.5 A each |
| Supply Current | 275 mA max. |
| Fixed Blanking | Yes |
| Auxiliary Output | Yes |
| Scan Code | Selectable |
| Trip/Latch Output | Selectable |
| Weight | 1.97 lb |
Information About SLSR30-300Q8
The SLSR30-300Q8 is a Banner Engineering 14/30 Series EZ-SCREEN receiver for hand-detection safety applications. It provides 30 mm resolution across a 300 mm defined area and supports operating distances from 0.1 to 18 m. The receiver has selectable scan code and trip/latch functions, fixed blanking, and auxiliary output capability. It is rated Type 4, PL e, and SIL 3/CL 3, making it intended for safety-related machine guarding systems.
Key Features:
- Safety Light Curtain Receiver: Provides protective sensing for machine guarding and personnel safety.
- 30 mm Resolution: Detects objects or personnel with a 30 mm resolution suitable for hand detection.
- 300 mm Protective Height: Provides a defined sensing area of 300 mm.
- 18 m Operating Range: Supports safety sensing across distances up to 18 m.
- Type 4 Safety Rating: Designed to meet Type 4 requirements under applicable machine-safety standards.
- High Safety Performance: Rated PL e and SIL 3/CL 3 for safety-related applications.
- M12 Quick Disconnect: Uses an integral 8-pin M12 connection for system wiring.
- Fixed Blanking: Provides fixed blanking functionality for appropriate machine-guarding configurations.
The SLSR30-300Q8 delivers the reliability and precision required for machine guarding, personnel protection, and industrial safety applications.
