Banner Engineering SSA-EB1PLGR-12ECQ8-WC Illuminated Emergency Stop Push Button
- Regular price
- $389.00
- Sale price
- $389.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: SSA-EB1PLGR-12ECQ8-WC
Description
The Banner Engineering SSA-EB1PLGR-12ECQ8-WC is an SSA-EB1 Series illuminated emergency stop push button designed for industrial machine-safety and emergency-stop applications. It features a 40 mm actuator, a green illuminated armed state and flashing red actuated state, with 2 NC and 1 NO contacts and an 8-pin M12 integral quick-disconnect connection. The assembly also includes an FDA-grade silicone washdown cover and provides IP65, IP67, and IP69 protection.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Banner Engineering |
| Category | Safety & Machine Controls |
| Part Number | SSA-EB1PLGR-12ECQ8-WC |
| Subcategory | Emergency Stop Push Buttons |
| Series | SSA-EB1 |
| Device Type | Illuminated Emergency Stop Push Button |
| Mounting | 30 mm |
| Actuator Diameter | 40 mm |
| Actuation | Twist/Pull-to-Release |
| Contact Configuration | 2 NC, 1 NO |
| Contact Rating | 2 A @ 24 VDC |
| Supply Voltage | 12–30 VDC |
| Connection | 8-pin M12 Integral Quick Disconnect |
| Armed Color | Green – Solid |
| Actuated Color | Red – Flashing |
| Illumination | LED Base |
| Housing Material | Polycarbonate |
| Actuator Material | Thermoplastic |
| IP Rating | IP65, IP67, IP69 |
| Operating Temperature | -25°C to +55°C |
| Washdown Rated | Yes |
| Washdown Cover | SSA-EB1P-ECWC included |
| Diagnostics | No In-Series Diagnostics |
| Dimensions | 120 × 86 mm |
| Weight | 1.53 lb |
Information About SSA-EB1PLGR-12ECQ8-WC
The SSA-EB1PLGR-12ECQ8-WC is a Banner Engineering SSA-EB1 illuminated emergency stop push button with a 30 mm mounting configuration. It operates from a 12–30 VDC supply and uses 2 NC and 1 NO contacts rated at 2 A at 24 VDC. The unit provides solid green illumination when armed and flashing red illumination when actuated, with twist/pull-to-release operation. The included SSA-EB1P-ECWC silicone washdown cover is designed for applications requiring frequent cleaning and washdown.
Key Features:
- Emergency Stop Function: Provides a manual emergency-stop interface for industrial machinery and safety systems.
- Illuminated Status: Uses solid green illumination when armed and flashing red illumination when actuated.
- 40 mm Actuator: Features a highly visible 40 mm thermoplastic emergency-stop button.
- Safety Contacts: Provides 2 NC and 1 NO contacts for integration with safety-control circuits.
- M12 Quick Disconnect: Uses an integral 8-pin M12 connection for industrial wiring.
- Washdown Cover: Includes an FDA-grade silicone cover for washdown environments.
- High Ingress Protection: Provides IP65, IP67, and IP69 protection.
- Twist/Pull Reset: Allows the emergency-stop button to be released by twisting or pulling.
The SSA-EB1PLGR-12ECQ8-WC delivers the reliability and precision required for machine emergency-stop systems, industrial safety controls, and washdown applications.
