Banner Engineering VE201G1A VE Series Smart Vision Camera
- Regular price
- $3,392.00
- Sale price
- $3,392.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: VE201G1A
Description
The Banner Engineering VE201G1A is a smart industrial vision camera designed for automated inspection, identification, positioning, and quality control applications. Featuring a 1.3 MP monochrome CMOS image sensor, onboard vision processing, and multiple industrial communication protocols, it provides reliable machine vision performance in demanding manufacturing environments.
Technical Specifications
| Condition | New |
| Brand | Banner Engineering |
| Part Number | VE201G1A |
| Category | Camera & Vision |
| Subcategory | Video Camera |
| Product Type | Smart Vision Camera |
| Series | VE |
| Image Sensor | CMOS |
| Image Type | Monochrome |
| Resolution | 1.3 MP (1280 × 1024 Pixels) |
| Lens Mount | C-Mount (Lens Required) |
| Supply Voltage | 12–30 VDC |
| Communication | EtherNet/IP, PROFINET, Modbus/TCP, RS-232, FTP |
| Digital I/O | 6 Optically Isolated I/O |
| Protection Rating | IP67 |
| Housing Material | Aluminum |
| Washdown Rated | Yes |
| Mounting Type | Chassis Mount |
| Operating Temperature | 0°C to +50°C |
| Software | Vision Manager Software Included |
| Dimensions (H × W × L) | 88 × 67 × 41 mm |
| Weight | 0.58 lbs |
Information About VE201G1A
The VE201G1A is part of Banner Engineering's VE Series Smart Cameras, combining image acquisition, processing, and industrial networking in a rugged IP67-rated housing. Equipped with a 1280 × 1024 monochrome CMOS sensor and a C-Mount lens interface, it supports applications such as presence verification, defect detection, part positioning, OCR, and traceability. Integrated Vision Manager Software and built-in industrial communication protocols enable seamless deployment without requiring an external vision controller.
Key Features:
- VE Series smart vision camera
- 1.3 MP monochrome CMOS image sensor
- 1280 × 1024 image resolution
- Integrated onboard image processing
- C-Mount lens interface (lens required)
- Six optically isolated digital I/O
- EtherNet/IP, PROFINET, Modbus/TCP, RS-232, and FTP communication
- IP67-rated aluminum housing
- Washdown-rated construction
- Compatible with Banner Vision Manager Software
The VE201G1A delivers high-performance industrial vision capabilities for inspection, identification, and quality control applications.
Description
The Banner Engineering VE201G1A is a smart industrial vision camera designed for automated inspection, identification, positioning, and quality control applications. Featuring a 1.3 MP monochrome CMOS image sensor, onboard vision processing, and multiple industrial communication protocols, it provides reliable machine vision performance in demanding manufacturing environments.
Technical Specifications
| Condition | New |
| Brand | Banner Engineering |
| Part Number | VE201G1A |
| Category | Camera & Vision |
| Subcategory | Video Camera |
| Product Type | Smart Vision Camera |
| Series | VE |
| Image Sensor | CMOS |
| Image Type | Monochrome |
| Resolution | 1.3 MP (1280 × 1024 Pixels) |
| Lens Mount | C-Mount (Lens Required) |
| Supply Voltage | 12–30 VDC |
| Communication | EtherNet/IP, PROFINET, Modbus/TCP, RS-232, FTP |
| Digital I/O | 6 Optically Isolated I/O |
| Protection Rating | IP67 |
| Housing Material | Aluminum |
| Washdown Rated | Yes |
| Mounting Type | Chassis Mount |
| Operating Temperature | 0°C to +50°C |
| Software | Vision Manager Software Included |
| Dimensions (H × W × L) | 88 × 67 × 41 mm |
| Weight | 0.58 lbs |
Information About VE201G1A
The VE201G1A is part of Banner Engineering's VE Series Smart Cameras, combining image acquisition, processing, and industrial networking in a rugged IP67-rated housing. Equipped with a 1280 × 1024 monochrome CMOS sensor and a C-Mount lens interface, it supports applications such as presence verification, defect detection, part positioning, OCR, and traceability. Integrated Vision Manager Software and built-in industrial communication protocols enable seamless deployment without requiring an external vision controller.
Key Features:
- VE Series smart vision camera
- 1.3 MP monochrome CMOS image sensor
- 1280 × 1024 image resolution
- Integrated onboard image processing
- C-Mount lens interface (lens required)
- Six optically isolated digital I/O
- EtherNet/IP, PROFINET, Modbus/TCP, RS-232, and FTP communication
- IP67-rated aluminum housing
- Washdown-rated construction
- Compatible with Banner Vision Manager Software
The VE201G1A delivers high-performance industrial vision capabilities for inspection, identification, and quality control applications.
