Banner Engineering XS26-2 Expandable Safety Controller
- Regular price
- $897.00
- Sale price
- $897.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: XS26-2
Description
The Banner Engineering XS26-2 is an expandable safety controller designed to monitor and manage complex machine safety systems. With 26 configurable safety inputs, dual OSSD safety outputs, and support for safety devices such as emergency stops, light curtains, safety mats, and gate switches, it provides flexible and reliable machine protection for industrial automation applications.
Technical Specifications
| Condition | New |
| Brand | Banner Engineering |
| Part Number | XS26-2 |
| Category | Safety Systems |
| Subcategory | Safety Controller |
| Product Type | Expandable Safety Controller |
| Series | XS26 |
| Module Type | Base Controller |
| Supply Voltage | 24 VDC ±20% |
| Power Supply | DC |
| Safe Inputs | 26 Configurable |
| Convertible Inputs | 8 |
| Safe Outputs | 4 (2 OSSD Pairs) |
| Non-Safe Outputs | Up to 11 PNP |
| Expandable | Yes (Up to 8 Expansion Modules) |
| Safety Rating | PLe, Category 4, SIL3 |
| Protection Rating | IP20 |
| Terminal Type | Screw, Removable |
| Operating Temperature | 0°C to +55°C |
| Dimensions (H × W × D) | 110 × 45 × 129 mm |
| Applications | E-Stop, Light Curtains, Gate Monitoring, Safety Mats, Two-Hand Control, Muting |
| Weight | 0.55 lbs |
Information About XS26-2
The XS26-2 is the base controller of Banner Engineering's XS26 Series Expandable Safety Controller platform. It supports up to eight expansion modules, allowing users to scale the system as safety requirements grow. The controller features 26 configurable safety inputs, four independently controlled safe outputs (two OSSD pairs), and up to 11 configurable non-safe PNP outputs. Designed for easy implementation, it includes intuitive configuration software with pre-configured safety function blocks for emergency stops, muting, two-hand control, gate monitoring, safety mats, and light curtains. Certified to PLe, Category 4, and SIL3, the XS26-2 is ideal for safeguarding complex industrial machinery.
Key Features:
- XS26 Series expandable safety controller
- 26 configurable safety inputs
- Four independently controlled safety outputs (2 OSSD pairs)
- Up to 11 configurable non-safe PNP outputs
- Supports up to 8 expansion I/O modules
- Compatible with E-Stops, light curtains, gate switches, safety mats, muting, and two-hand controls
- Certified to PLe, Category 4, and SIL3 safety standards
- Screw terminal connections with removable terminals
- Intuitive configuration software with pre-configured safety function blocks
- Compact DIN rail mounting design
The XS26-2 provides scalable machine safety control for complex industrial automation systems.
Description
The Banner Engineering XS26-2 is an expandable safety controller designed to monitor and manage complex machine safety systems. With 26 configurable safety inputs, dual OSSD safety outputs, and support for safety devices such as emergency stops, light curtains, safety mats, and gate switches, it provides flexible and reliable machine protection for industrial automation applications.
Technical Specifications
| Condition | New |
| Brand | Banner Engineering |
| Part Number | XS26-2 |
| Category | Safety Systems |
| Subcategory | Safety Controller |
| Product Type | Expandable Safety Controller |
| Series | XS26 |
| Module Type | Base Controller |
| Supply Voltage | 24 VDC ±20% |
| Power Supply | DC |
| Safe Inputs | 26 Configurable |
| Convertible Inputs | 8 |
| Safe Outputs | 4 (2 OSSD Pairs) |
| Non-Safe Outputs | Up to 11 PNP |
| Expandable | Yes (Up to 8 Expansion Modules) |
| Safety Rating | PLe, Category 4, SIL3 |
| Protection Rating | IP20 |
| Terminal Type | Screw, Removable |
| Operating Temperature | 0°C to +55°C |
| Dimensions (H × W × D) | 110 × 45 × 129 mm |
| Applications | E-Stop, Light Curtains, Gate Monitoring, Safety Mats, Two-Hand Control, Muting |
| Weight | 0.55 lbs |
Information About XS26-2
The XS26-2 is the base controller of Banner Engineering's XS26 Series Expandable Safety Controller platform. It supports up to eight expansion modules, allowing users to scale the system as safety requirements grow. The controller features 26 configurable safety inputs, four independently controlled safe outputs (two OSSD pairs), and up to 11 configurable non-safe PNP outputs. Designed for easy implementation, it includes intuitive configuration software with pre-configured safety function blocks for emergency stops, muting, two-hand control, gate monitoring, safety mats, and light curtains. Certified to PLe, Category 4, and SIL3, the XS26-2 is ideal for safeguarding complex industrial machinery.
Key Features:
- XS26 Series expandable safety controller
- 26 configurable safety inputs
- Four independently controlled safety outputs (2 OSSD pairs)
- Up to 11 configurable non-safe PNP outputs
- Supports up to 8 expansion I/O modules
- Compatible with E-Stops, light curtains, gate switches, safety mats, muting, and two-hand controls
- Certified to PLe, Category 4, and SIL3 safety standards
- Screw terminal connections with removable terminals
- Intuitive configuration software with pre-configured safety function blocks
- Compact DIN rail mounting design
The XS26-2 provides scalable machine safety control for complex industrial automation systems.
