Banner Engineering XS26-2E Ethernet Safety Controller
- Regular price
- $1,072.00
- Sale price
- $1,072.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: XS26-2E
Description
The Banner Engineering XS26-2E is an Ethernet-enabled expandable safety controller designed to monitor and control complex machine safety systems. With 26 configurable safety inputs, integrated industrial Ethernet communications, modular expansion capability, and support for advanced safety devices, it provides scalable protection for industrial automation and machine safeguarding applications.
Technical Specifications
| Condition | New |
| Brand | Banner Engineering |
| Part Number | XS26-2E |
| Category | Safety Systems |
| Subcategory | Safety Controller |
| Product Type | Expandable Safety Controller |
| Series | XS26-2 |
| Module Type | Base Controller |
| Supply Voltage | 24 VDC |
| Power Supply | DC |
| Safe Inputs | 26 Configurable Digital Inputs |
| Convertible Inputs | 8 |
| Safe Outputs | 4 (2 OSSD Pairs) |
| Non-Safe Outputs | Up to 11 PNP |
| Output Rating | 0.5 A @ 24 VDC |
| Expandable | Up to 8 Expansion Modules |
| Communication | EtherNet/IP, PROFINET, Modbus/TCP, PCCC |
| Safety Rating | Category 4, PLe, SIL3 |
| Protection Rating | IP20 (IP54 with enclosure) |
| Mounting Type | DIN Rail |
| Terminal Type | Screw Terminal |
| Operating Temperature | 0°C to +55°C |
| Dimensions (H × W × D) | 110 × 45 × 129 mm |
| Approval Agency | CE, cULus, UL |
| Weight | 0.58 lbs |
Information About XS26-2E
The XS26-2E is the Ethernet version of Banner Engineering's XS26 Series Expandable Safety Controllers. It combines configurable safety logic with integrated EtherNet/IP, PROFINET, and Modbus/TCP communications for seamless PLC and HMI integration. The controller supports 26 configurable safety inputs, four independently controlled safe outputs (two OSSD pairs), and up to eleven configurable non-safe PNP outputs. It can be expanded with up to eight additional I/O modules, making it suitable for both standalone and large-scale machine safety systems. Certified to Category 4, PLe, and SIL3, the XS26-2E is ideal for emergency stops, light curtains, safety mats, gate monitoring, muting, and two-hand control applications.
Key Features:
- XS26 Series Ethernet-enabled safety controller
- 26 configurable safety inputs
- Four independently controlled safety outputs (2 OSSD pairs)
- Up to 11 configurable non-safe PNP outputs
- Supports up to 8 expansion I/O modules
- Built-in EtherNet/IP, PROFINET, and Modbus/TCP communications
- Supports E-Stops, light curtains, gate switches, safety mats, muting, and two-hand controls
- Certified to Category 4, PLe, and SIL3 safety standards
- Screw terminals with removable connectors
- DIN rail mounting with IP20 protection
The XS26-2E delivers scalable machine safety control with integrated industrial Ethernet connectivity.
