SC10-2ROE | Banner Safety Controller with 10 Inputs and Dual Relay Outputs
- Regular price
- $609.00
- Sale price
- $609.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: SC10-2ROE
Description
The Banner SC10-2ROE safety controller is a compact base controller designed for machine safety monitoring and control applications. It provides configurable safe inputs and dual relay outputs to manage safety devices such as emergency stops, light curtains, and interlocks. This controller supports in-series diagnostics for improved fault detection and system reliability.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Banner Engineering |
| Category | Safety Control |
| Part Number | SC10-2ROE |
| Subcategory | Safety Controllers |
| Device Type | Base Safety Controller |
| Supply Voltage | 24 V DC |
| Power Consumption | 0.24 A (no load), 0.53 A (full load) |
| Number of Safe Inputs | 10 |
| Number of Convertible Inputs | 4 |
| Input Configuration | Configurable |
| Safety Output Configuration | 2 sets of 3 NO relay outputs |
| Safe Output Rating | 6 A |
| Non-Safe Outputs | Up to 4 PNP |
| Non-Safe Output Rating | 80 mA @ 24 V DC |
| In-Series Diagnostics | Yes |
| Safety Category Rating | Category 4 |
| Performance Level | PL e |
| SIL Rating | SIL 3 |
| Operating Temperature | Up to 55 °C |
| Relative Humidity | 90% @ 50 °C |
| Terminal Type | Push-In Spring Clamp |
| Dimensions (H x W x D) | 115 x 45 x 100 mm |
| Weight | 1.00 lb |
Information About SC10-2ROE
The SC10-2ROE is part of Banner Engineering’s SC10 safety controller family, designed as a standalone base controller for safety-critical applications. It supports up to two ISD chains and includes ten configurable safety inputs, four of which can be converted for non-safety use. The controller is engineered for direct wiring of safety devices using push-in spring clamp terminals and operates on a 24 V dc supply. Its architecture supports high safety integrity levels, making it suitable for machinery requiring Category 4, PL e, and SIL 3 compliance.
Key Features:
- ISD Compatibility: Supports two in-series diagnostic chains for advanced fault detection.
- Ten Configurable Safe Inputs: Allows flexible connection of multiple safety devices.
- Dual Relay Safety Outputs: Provides two independently controlled relay outputs rated at 6 A.
- Convertible Inputs: Includes four inputs that can be configured for non-safety functions.
- High Safety Ratings: Certified to Category 4, PL e, and SIL 3 requirements.
- Compact DIN-Mount Design: Optimized for control panels with limited space.
- Push-In Spring Clamp Terminals: Enables secure and tool-free wiring connections.
The SC10-2ROE delivers the reliability and precision required for machine safety control and industrial safeguarding systems.
