Belimo NFBUP Spring-Return Damper Actuator, 90 in-lb, 24–240 VAC / 24–125 VDC, On/Off Control
- Regular price
- $415.00
- Sale price
- $415.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: NFBUP
Description
The Belimo NFBUP is a spring-return damper actuator designed for on/off airflow control in commercial HVAC systems. It delivers 90 in-lb of torque and operates on 24–240 VAC or 24–125 VDC, accommodating a wide range of control power supplies. Its mechanical spring returns the damper to the selected fail-safe position when power is removed.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Belimo |
| Category | HVAC & Building Automation |
| Part Number | NFBUP |
| Subcategory | Damper Actuators |
| Series | NF Series |
| Control Type | On/Off; spring-return fail-safe |
| Nominal Supply Voltage | 24–240 VAC / 24–125 VDC |
| AC Supply Frequency | 50/60 Hz |
| Power Consumption | 6 W running; 2.5 W holding |
| Power Supply Sizing | 9.5 VA |
| Torque | 90 in-lb |
| Rotation / Direction | Maximum 95°; mechanical stop adjustable from 35° to 95°; CW/CCW selectable by mounting |
| Motor Running Time | 75 seconds per 90° |
| Spring-Return Running Time | Under 20 seconds at −4–122°F; under 60 seconds at −22°F |
| Manual Override | Supplied 5 mm hex crank, designated 3/16-inch Allen |
| Mounting | Direct coupled; compatible damper shafts up to 1.05 inches in diameter |
| Electrical Connection | Approximately 3 ft, 18 AWG appliance cable with 1/2-inch NPT conduit connector |
| Enclosure / Ambient Conditions | NEMA 2; UL Enclosure Type 2; −22–122°F; maximum 95% RH, non-condensing |
| Weight | 4.1 lb |
Information About NFBUP
The NFBUP is part of Belimo’s NF Series of direct-coupled, spring-return actuators for HVAC air dampers. A universal shaft clamp allows installation on compatible damper shafts up to 1.05 inches in diameter, while mounting orientation determines clockwise or counterclockwise operation. The actuator responds to switched power from an external control contact or manual switch and includes electronic overload protection throughout its operating travel. An adjustable mechanical end stop, graduated position indicator, and supplied manual crank support installation and damper positioning.
Key Features:
- On/Off Control: Provides two-position damper operation through an external switching contact.
- Wide Supply Range: Accepts 24–240 VAC or 24–125 VDC power.
- Torque Output: Delivers 90 in-lb for operating appropriately sized HVAC dampers.
- Mechanical Spring Return: Drives the damper to its selected fail-safe position following power loss.
- Reversible Installation: Supports clockwise or counterclockwise operation through mounting orientation.
- Direct Shaft Mounting: Uses a universal clamp for compatible damper shafts up to 1.05 inches in diameter.
- Adjustable Travel: Provides up to 95° rotation with a mechanical stop adjustable from 35° to 95°.
- Manual Override: Includes a 5 mm hex crank for manual positioning.
- Overload Protection: Electronically protects the actuator throughout its rotation range.
- Position Indication: Displays damper position through a graduated mechanical indicator.
The NFBUP delivers the reliability and precision required for two-position airflow control and fail-safe damper operation in commercial HVAC systems.
