Belimo NM24A-SR 10 Nm Proportional Non-Spring-Return Damper Actuator
- Regular price
- $399.00
- Sale price
- $399.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: NM24A-SR
Description
Belimo NM24A-SR is a non-spring-return rotary actuator designed for proportional control of HVAC air dampers. It operates on 24 VAC/DC, provides 10 Nm of torque, and uses a 2–10 VDC control signal with a 150-second running time for 90° rotation.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Belimo |
| Category | Building Automation / HVAC Controls |
| Part Number | NM24A-SR |
| Subcategory | Damper Actuators |
| Product Type | Non-Spring-Return Rotary Actuator |
| Power Supply | AC/DC 24 V |
| Control Signal | DC 2–10 V |
| Torque | 10 Nm |
| Running Time | 150 s / 90° |
| Angle of Rotation | 95° |
| Shaft Compatibility | 8–26.7 mm |
| Power Consumption, Running | 2 W |
| Power Consumption, Holding | 0.4 W |
| Protection Rating | IP54 |
| Ambient Temperature | -30°C to +50°C |
| Manual Override | Push-button, lockable |
| Weight | 0.73 kg |
Information About NM24A-SR
The NM24A-SR belongs to Belimo’s NM series of non-fail-safe damper actuators and is designed for direct mounting on HVAC damper shafts. Its universal shaft clamp accommodates shafts from 8 to 26.7 mm and includes an anti-rotation mechanism for secure installation. The actuator provides adjustable rotation up to 95° and includes a push-button manual override that can be locked. Its IP54 enclosure and operating range of -30°C to 50°C support use in a range of commercial HVAC environments.
Key Features:
- 10 Nm Torque: Provides the required driving force for compatible HVAC damper applications.
- Proportional Control: Uses a DC 2–10 V control signal for adjustable damper positioning.
- 24 V Supply: Operates from 24 VAC or 24 VDC power.
- Non-Spring Return: Maintains the commanded damper position without spring-return operation.
- 150-Second Running Time: Completes a 90° rotation in approximately 150 seconds.
- Universal Shaft Clamp: Fits damper shafts from 8 to 26.7 mm in diameter.
- Manual Override: Push-button mechanism allows manual positioning and can be locked.
- IP54 Protection: Provides protection suitable for standard HVAC actuator installations.
The NM24A-SR delivers the reliability and precision required for proportional air damper control in HVAC and building automation systems.
