Belimo UGLK1806 RetroFIT+ Linkage Kit for Honeywell V5011/V5013 1/2–2-Inch Globe Valves
- Regular price
- $1,185.00
- Sale price
- $1,185.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: UGLK1806
Description
The Belimo UGLK1806 is a RetroFIT+ linkage kit designed to connect compatible Belimo rotary actuators to selected Honeywell V5011 and V5013 globe valves. It converts rotary actuator movement into a 3/4-inch linear stroke for valve positioning in HVAC water systems. The kit supports actuator replacement while retaining the installed valve body; the actuator is sold separately.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Belimo |
| Category | HVAC & Building Automation |
| Part Number | UGLK1806 |
| Subcategory | Valve Retrofit Linkage Kits |
| Series | RetroFIT+ / UGLK |
| Product Type | Rotary-actuator-to-globe-valve retrofit linkage |
| Valve Compatibility | Selected Honeywell V5011 and V5013 globe valves |
| Applicable Valve Sizes | 1/2–2 inches |
| Linear Stroke / Gearing | 3/4 inch; 17 teeth |
| Actuator Rotation | 95° for specified linkage travel |
| Mounting Position | 360° orientation around the valve bonnet |
| Suitable Non-Spring-Return Actuators | Belimo LMB/LMX and NMB/NMX families, subject to application selection |
| Suitable Spring-Return Actuators | Belimo LF and NFB/NFX families, subject to application selection |
| Frame / Plate / Base / Hardware | Stainless steel |
| Spindle / Stem Adapter / Collar | Brass |
| Bearing / Rack | Bronze bearing; sintered steel rack |
| Temperature / Close-Off Limits | Depend on the existing valve and selected actuator combination |
| Weight | 1.00 lb |
Information About UGLK1806
The UGLK1806 is part of Belimo’s UGLK retrofit linkage family for upgrading existing globe-valve installations. Its rack-and-pinion mechanism translates 95° of actuator rotation into downward stem travel through a 17-tooth gearing configuration. Stainless steel structural components, brass adapters, and a bronze bearing form the mechanical assembly. The mounting collar permits 360° orientation around the valve bonnet to accommodate available installation space.
Key Features:
- Honeywell Valve Compatibility: Fits selected V5011 and V5013 globe valves, subject to the specific valve configuration.
- Valve Size Range: Supports applicable valve sizes from 1/2 inch through 2 inches.
- Defined Linear Stroke: Provides 3/4-inch stem travel using a 17-tooth gearing arrangement.
- Rotary-to-Linear Conversion: Transfers rotary actuator movement to the globe-valve stem through a rack-and-pinion mechanism.
- Flexible Mounting: Allows 360° orientation around the valve bonnet.
- Existing Valve Retention: Enables actuator upgrades without removing the compatible valve body from the piping.
- Stainless Steel Structure: Uses stainless steel hardware, frame, actuator plate, and base.
- Brass Interface Components: Incorporates a brass spindle, stem adapter, and mounting collar.
- Bronze Bearing: Supports the linkage’s moving mechanical components.
- Actuator Selection: Accommodates specified Belimo spring-return and non-spring-return actuator families.
- Separate Actuator Supply: Allows selection of a compatible actuator with the required control signal and operating characteristics.
The UGLK1806 delivers the reliability and precision required for transferring actuator motion to compatible globe valves during HVAC retrofit projects.
