BGA261001 | Schneider Electric Square D 100A 2-Pole 600Y/347VAC PowerPact B Molded Case Breaker
- Regular price
- $1,205.00
- Sale price
- $1,205.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: BGA261001
Description
The Square D BGA261001 by Schneider Electric is a 2-Pole thermal magnetic molded case circuit breaker designed for reliable overcurrent and short-circuit protection in low-voltage electrical systems. Rated at 100 amps and 600Y/347VAC, this breaker features an interrupting capacity of up to 100kA at 240VAC. Its I-Line plug-in connection design ensures quick installation and robust mechanical and electrical performance in commercial and industrial applications.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Schneider Electric / Square D |
| Category | Circuit Breakers |
| Part Number | BGA261001 |
| Subcategory | Molded Case Circuit Breakers |
| Series | PowerPact B-Frame |
| Amperage Rating | 100A |
| Voltage Rating | 600Y/347VAC |
| Interrupting Capacity | 100kA @ 240VAC |
| Number of Poles | 2 |
| Phase | Single-Phase |
| Trip Unit Type | Thermal Magnetic |
| Functions | Long-Time and Instantaneous Trip |
| Connection Type | I-Line Style Plug-In (line side), Mechanical Lugs (load side) |
| Frame Type | BGA Frame |
| Rated Frequency | 50/60 Hz |
| Operating Temperature | -13°F to 158°F (-25°C to 70°C) |
| Wire Range | AWG 14 to AWG 2/0 (Aluminum/Copper) |
| Approvals and Standards | UL, CSA, CE, IEC, NOM, CCC, NEMA, EAC, GB, RoHS |
| Protection Type | Thermal-Magnetic |
| Insulation Voltage (Ui) | 800V (IEC 60947-2) |
| Impulse Withstand Voltage (Uimp) | 8kV |
| Mounting Type | I-Line Panel Mount |
| Dimensions (HxWxD) | 5.39 x 2.13 x 3.5 in |
| Weight | 2.10 lb |
Information About BGA261001
The BGA261001 is part of Schneider Electric’s PowerPact B-frame circuit breaker series, engineered for high-efficiency protection and compact installation. Built with a thermal-magnetic trip unit, it combines overload and short-circuit protection in one durable, molded case. The breaker utilizes an I-Line plug-in connection on the line side and mechanical lugs on the load side, enabling safe and efficient mounting within distribution panels. Compliant with global standards including UL, CSA, IEC, and CE, the BGA261001 ensures consistent protection performance across diverse installation environments.
Key Features:
- High Interrupting Capacity: Rated up to 100kA at 240VAC for reliable fault current protection.
- Thermal Magnetic Protection: Dual-function trip unit offers both overload and instantaneous short-circuit response.
- Compact B-Frame Design: Optimized for space-saving installations in commercial and industrial panels.
- I-Line Plug-In Connection: Provides fast, secure mounting and enhanced serviceability.
- Durable Molded Case: Resistant to impact and heat, ensuring long service life under demanding conditions.
- Wide Temperature Range: Operates from -13°F to 158°F (-25°C to 70°C) for varied environments.
- Global Compliance: Meets UL 489, CSA, CE, and IEC 60947-2 standards for international applications.
- Versatile Wire Compatibility: Supports AWG 14 to AWG 2/0 aluminum or copper conductors.
The BGA261001 delivers the reliability and precision required for safe, high-performance electrical distribution and circuit protection.
