BGA261002 | Square D 2-Pole 100A PowerPact B-Frame Thermal Magnetic Circuit Breaker
- Regular price
- $1,112.00
- Sale price
- $1,112.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: BGA261002
Description
The Square D BGA261002 is a 2-pole thermal-magnetic molded case circuit breaker designed for reliable power distribution and protection in commercial and industrial electrical systems. With a current rating of 100A and a voltage rating of 600Y/347 VAC, it provides dependable circuit protection against overloads and short circuits. Its PowerPact™ B-frame design ensures high interrupting performance of 18kA while maintaining a compact form factor.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Square D |
| Category | Circuit Breakers |
| Part Number | BGA261002 |
| Subcategory | Molded Case Circuit Breakers |
| Frame Type | PowerPact B-Frame |
| Rated Current | 100 A |
| Number of Poles | 2 |
| Voltage Rating | 600Y/347 VAC |
| Interrupting Rating | 18 kA at 600Y/347 VAC |
| Trip Type | Thermal-Magnetic |
| Mounting Type | I-Line Plug-On |
| Connection Type | I-Line (line) / Lugs (load) |
| Frequency | 50/60 Hz |
| Rated Insulation Voltage (Ui) | 800 V |
| Impulse Withstand Voltage (Uimp) | 8 kV |
| Electrical Durability | 10,000 cycles |
| Mechanical Durability | 20,000 cycles |
| Operating Temperature | -25°C to +70°C |
| Certifications | UL, CSA, NOM, IEC, CE, CCC, EAC |
| Protection Degree | IP40 (front cover) |
| Height | 5.4 in (137 mm) |
| Width | 2.1 in (54 mm) |
| Depth | 3.5 in (89 mm) |
| Weight | 0.95 kg (2.1 lb) |
Information About
BGA261002
The BGA261002 is part of the Square D PowerPact™ B-series circuit breakers, engineered for robust protection and compact efficiency. It features a thermal-magnetic trip unit that provides long-time and instantaneous protection functions for AC applications. The unit is compatible with I-Line panelboards, offering a shrouded plug-on jaw connection for easy installation. With UL, CSA, NOM, and IEC certifications, this breaker ensures compliance with global safety and performance standards, making it ideal for critical power distribution applications.
Key Features:
- Compact B-Frame Design: Provides high performance in a space-saving molded case enclosure.
- Thermal-Magnetic Trip Unit: Ensures reliable overload and short-circuit protection.
- High Interrupting Capacity: Rated up to 18kA at 600Y/347 VAC for superior fault protection.
- I-Line Mounting System: Simplifies installation and maintenance in I-Line panelboards.
- Durable Construction: Rated for 20,000 mechanical and 10,000 electrical operations for long life.
- Wide Environmental Range: Operates reliably from -25°C to 70°C for harsh environments.
- Standards Compliance: Meets UL 489, CSA C22.2, and IEC 60947-2 requirements for safety.
- Front-Accessible Trip Button: Allows manual trip testing and verification of breaker function.
The BGA261002 delivers the reliability and precision required for commercial, industrial, and utility-grade electrical distribution systems.
