BGA36125 | Schneider Electric PowerPacT B 125A 3-Pole 600Y/347VAC I-Line Thermal Magnetic Breaker
- Regular price
- $825.00
- Sale price
- $825.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: BGA36125
Description
The Schneider Electric BGA36125 is a 3-pole PowerPacT B molded case circuit breaker rated for 125 amps and 600Y/347 VAC systems. Designed with thermal-magnetic protection, it provides dependable long-time and instantaneous overcurrent safeguarding in commercial and industrial distribution panels. With its I-Line plug-in mounting and robust interrupting capability, the BGA36125 delivers reliable performance for feeder and branch circuit applications.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Schneider Electric |
| Category | Circuit Breaker |
| Part Number | BGA36125 |
| Subcategory | Molded Case Circuit Breaker |
| Series | BGA (PowerPacT B) |
| Amperage | 125 A |
| Voltage Rating | 600Y/347 VAC |
| Poles | 3 |
| Phase | 3-phase |
| Frame Type | B Frame |
| Interrupting Rating | 35 kA @ 480 VAC |
| Mounting Type | I-Line plug-in |
| Connection Type | I-Line style plug-in |
| Protection Type | Thermal-magnetic |
| Trip Functions | LI – Long-time, instantaneous |
| Continuous Rating | 80% |
| Approvals | UL, IEC, CCC, EAC, CSA, NOM |
| Wire Gauge Compatibility | AWG 14 to AWG 2/0, Al/Cu |
| Length | 3.5 in |
| Width | 3.19 in |
| Height | 5.39 in |
Information About BGA36125
The BGA36125 is part of Schneider Electric’s PowerPacT B Series, engineered to provide compact yet high-performance protection in three-phase electrical systems. Built with a B-frame molded case, this breaker supports an 80% continuous rating and incorporates LI (long-time and instantaneous) trip functions for effective coordination with upstream and downstream protective devices. Its I-Line plug-in connection system enables quick installation into Square D I-Line panels, enhancing serviceability in high-demand environments. Typical applications include commercial distribution boards, industrial control panels, and facility power systems requiring reliable 125-amp, 3-pole circuit protection.
Key Features:
- PowerPacT B molded case design: Compact frame with robust protection features.
- 125A, 3-pole rating: Suitable for three-phase circuits in industrial and commercial systems.
- 600Y/347 VAC capability: Supports common high-voltage distribution configurations.
- Thermal-magnetic trip: Provides long-time and instantaneous protection (LI).
- I-Line mounting: Plug-in connection for fast installation and serviceability.
- 35 kA interrupting rating @ 480 V: Supports high-fault environments.
- UL/IEC/CSA certified: Approved for global compliance and safety standards.
- ABC trip curve: Ensures dependable response to overload and short-circuit events.
The BGA36125 delivers the reliability and precision required for high-performance electrical distribution applications.
