BMEXBP0800 | Schneider Electric Ethernet backplane

Description

 The BMEXBP0800 is a rack designed for the Modicon X80 series, serving as an 8-slot Ethernet backplane for use with Modicon M580 and M340 Programmable Automation Controllers (PAC). This rack facilitates the integration of various modules into automation systems. It features 8 slots with connectors supporting both Ethernet and X-bus connections, enabling the accommodation of mixed modules.

As a robust and high-quality product, it incorporates advanced technology to ensure reliable performance. The Ethernet backplane rack operates with a current of 164mA at 24V DC and 64mA at 3.3V DC. It includes 1 connector (XBE) expansion module for electrical connection and offers an impressive mean time between failures (MTBF) of 1700000 hours.

With an IP20 rating, this rack provides protection against solid objects and is suitable for medium to large process applications. It complies with standards such as EN 61131-2, EN 61000-6-4, EN 61000-6-2, and EN 61010-2-201, ensuring adherence to safety and performance requirements.

Technical Specifications

Information About BMEXBP0800

The BMEXBP0800 is a rack designed for use with Modicon X80 series, serving as an integral component within the range's ecosystem tailored for Modicon M580 and M340 Programmable Automation Controllers (PAC). As an Ethernet backplane rack, it serves as an accessory for programmable automation controllers, providing essential connectivity and expansion options.

Featuring 8 slots, this dual Ethernet and X-bus backplane facilitates mixed module configurations, offering versatility and adaptability to various industrial automation setups. Engineered with robust construction and leveraging cutting-edge technology, the BMEXBP0800 ensures reliability and high performance in demanding industrial environments.

Operating at 164mA at 24V DC and 64mA at 3.3V DC, this Ethernet backplane rack efficiently manages power consumption while delivering reliable connectivity. Equipped with a single connector (XBE) expansion module, it simplifies electrical connections and enhances installation convenience.

With a mean time between failures (MTBF) rating of 1,700,000 hours, the BMEXBP0800 demonstrates exceptional reliability, ensuring continuous operation with minimal downtime. Rated at IP20, it offers protection against solid objects and ingress of fingers or similar objects.
