BMXCPS2010 | Schneider Electric Power Supply Module, Modicon X80, 24V DC, 16.8W
- Regular price
- $242.00
- Sale price
- $242.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: BMXCPS2010
Description
The Schneider Electric BMXCPS2010 is a 24 VDC isolated power supply module engineered for the Modicon X80 platform supporting M580 and M340 PAC systems. It provides stable secondary power for backplane logic and I/O modules, delivering 16.8 W at 24 VDC and up to 2.5 A at 3.3 VDC. Designed for reliable industrial operation, the module features an IP20 enclosure, integrated protection functions, and efficient power distribution for automation architectures.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Schneider Electric |
| Category | Power Supplies |
| Part Number | BMXCPS2010 |
| Subcategory | Power Supply |
| Input Voltage | 24 VDC |
| Input Current | 1 A |
| Output Voltage | 24 VDC (module power), 3.3 VDC (logic power) |
| Output Current | 0.7 A at 24 VDC; 2.5 A at 3.3 VDC |
| Secondary Power | 16.8 W at 24 VDC |
| Power Dissipation | ≤ 8.5 W |
| Inrush Current | 30 A at 24 VDC |
| Protection Features | Overload, overvoltage, short-circuit, internal fuse |
| LED Indicators | Rack voltage OK |
| Controls | RESET pushbutton |
| Connectors | 2-pin alarm relay; 5-pin line supply/PE/24V sensor input |
| Insulation Resistance | ≥10 MΩ primary/ground and primary/secondary |
| Dielectric Strength | 1500 V primary/ground; 1500 V primary/secondary |
| Operating Temperature | 32–140 °F |
| Storage Temperature | -40–185 °F |
| Humidity Rating | 10–95% non-condensing |
| Enclosure Rating | IP20 |
| Type | Standard Isolated Power Supply |
| Certifications | CE, UL, CSA, EAC, RCM, Merchant Navy |
Information About BMXCPS2010
The BMXCPS2010 is part of the Modicon X80 common module platform, enabling consistent deployment across Schneider Electric M580 and M340 controller systems. Its construction includes an isolated 24 VDC supply, built-in diagnostics, LED rack voltage indication, and connectors for alarm relay and line supply wiring. Integration within the X80 ecosystem allows the module to support both processor and I/O module power requirements, with protection mechanisms for overload, overvoltage, and short circuits. Typical applications include medium to large automation installations requiring stable rack power, high immunity to electrical disturbances, and compliance with industrial standards such as EN 61131-2 and EN 61000-6-2.
Key Features:
- Isolated 24 VDC input: Provides clean, stable power for Modicon X80 systems.
- Dual secondary outputs: Supplies 0.7 A at 24 VDC and 2.5 A at 3.3 VDC for modules and logic circuits.
- Integrated protection: Includes overload, overvoltage, short-circuit, and internal fuse protection.
- Front-panel diagnostics: Equipped with a rack voltage OK LED and RESET pushbutton.
- Industrial compliance: Meets global standards including CE, UL, CSA, RCM, and EN 61131-2.
- IP20 enclosure: Suitable for installation within protected control cabinets.
- Wide environmental range: Operating from 32–140 °F with robust storage temperature capability.
- Modicon X80 compatibility: Supports M580 and M340 PACs for unified module architecture.
The BMXCPS2010 delivers the reliability and precision required for powering modern Modicon X80 automation systems.
