BMXDDI1602 | Schneider Electric Discrete Input Module, M340, 16 Inputs, 24 VDC sink
- Regular price
- $234.00
- Sale price
- $234.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: BMXDDI1602
Description
The Schneider Electric BMXDDI1602 is a digital input module designed for use with Modicon X80 I/O systems and M340/M580 PLC platforms. It provides 16 opto-isolated 24V DC input channels for monitoring field signals. This unit is widely used in machine automation, material handling, and process control systems.
Technical Specifications
| Brand | Schneider Electric |
| Module Type | Digital Input Module |
| Suitable for | Modicon X80 |
| Input Type | Digital |
| Inputs | 16 |
| Mounting Type | DIN Rail Mount |
| Termination Type | Connector |
| Operating Voltage Max. - DC | 24 V |
| Operating Voltage Min. - DC | 19 V |
Information About BMXDDI1602
The BMXDDI1602 is part of the Schneider Electric Modicon X80 module family, developed to offer modular and high-performance I/O for Modicon PLCs. It features 16 sinking (negative logic) digital inputs for detecting 24V DC signals from sensors, switches, and pushbuttons. The module includes opto-isolation between channels and the backplane to protect the PLC from electrical noise and transients. Status LEDs are provided for each input channel, simplifying commissioning and troubleshooting. It mounts on an X80 rack and communicates with the CPU over the X-bus backplane. Configuration and diagnostics are performed using EcoStruxure Control Expert (Unity Pro) software, enabling seamless integration into Modicon M340 and M580 systems.
Key Features:
- Design: 16-channel digital input module for Modicon X80 systems.
- Signal Type: 24V DC sinking (negative logic) digital inputs.
- Isolation: Opto-isolated channels for noise immunity and system protection.
- Diagnostics: Per-channel status LEDs for fast troubleshooting.
- Integration: Compatible with Modicon M340 and M580 PLC platforms.
- Configuration: Engineered using EcoStruxure Control Expert (Unity Pro).
- Installation: Rack-mounted module for X80 backplane systems.
- Application Range: Suitable for machine control, material handling, and process automation.
The BMXDDI1602 delivers the channel density, reliability, and noise immunity required for robust digital signal acquisition in Modicon-based automation systems.
