Bosch D7412GV3 Commercial Security & Fire Alarm Integrated Control Panel with Access Control Support
- Regular price
- $299.00
- Sale price
- $299.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: D7412GV3
Description
The Bosch D7412GV3 Control Panel is an advanced integrated security and fire alarm platform designed for commercial intrusion detection, access control, and life safety applications. Featuring support for up to 75 programmable points, this panel delivers reliable event monitoring, flexible communication routing, and scalable expansion capabilities for professional security installations. The Bosch D7412GV3 supports remote programming, multiple area configurations, and integrated access control for demanding commercial environments.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Bosch |
| Category | Security & Fire Alarm Systems |
| Part Number | D7412GV3 |
| Subcategory | Control Panels |
| Supported Points | 75 Total (8 Onboard, Up to 67 Off-board) |
| Areas Supported | 8 |
| Access Control Doors | Up to 2 |
| Passcode Users | 99 Plus 1 Service Passcode |
| Event Storage Capacity | Up to 1,000 Events |
| Programmable Relay Outputs | Up to 67 |
| RF Points Supported | 67 |
| SKED Schedules | 40 |
| Operating Voltage | 12 VDC Nominal |
| Transformer Requirement | 16.5 VAC 40 VA Plug-in Transformer (D1640) |
| Alarm Output | 2 A at 12 VDC |
| Auxiliary Output | 1.4 A at 12 VDC Nominal |
| Maximum Current Draw | 300 mA |
| Operating Temperature | 0°C to +50°C (+32°F to +122°F) |
| Relative Humidity | 5% to 93% Non-Condensing |
| Telephone Line Support | One Telephone Line (Two with D928 Module) |
| Communication Compatibility | PSTN, IP, GPRS/GSM |
| SDI Bus Distance | Up to 4572 m (15,000 ft) |
| Keypad Capacity | 16 Supervised / 32 Unsupervised |
| Weight | Approximately 5 lb |
Information About D7412GV3
The D7412GV3 is a commercial-grade security and fire alarm control panel engineered by Bosch as part of the G Series control platform. It supports intrusion, fire supervisory, and access control applications with programmable point configuration for both normally-open and normally-closed devices using EOL resistor supervision. The panel accommodates up to eight independent areas, remote programming through Bosch RPS software, and optional integration with D9210BLC access control modules for door management functions. Designed for high-reliability commercial installations, the system incorporates advanced communication routing, programmable authority levels, skeds, relay outputs, and encrypted IP or GPRS reporting capabilities.
Key Features:
- Integrated Security Platform: Combines intrusion detection, access control, and fire alarm monitoring within a single control panel.
- 75 Programmable Points: Supports 8 onboard points and up to 67 expandable off-board points for scalable installations.
- Flexible Communication Routing: Provides PSTN, IP, and GPRS reporting through four programmable route groups.
- Remote Programming Support: Compatible with Bosch Remote Programming Software (RPS) for attended or unattended configuration.
- Multi-Area Operation: Supports up to 8 independently controlled areas with shared-area functionality.
- Access Control Integration: Supports up to two controlled doors using optional D9210BLC access modules.
- Advanced User Authority Levels: Includes 14 customizable authority levels with area-specific permissions.
- Programmable Relay Outputs: Supports up to 67 programmable relay outputs for automation and alarm control.
- Event Log Storage: Stores up to 1,000 system events for diagnostics and reporting.
- Enhanced Security Functions: Includes Two Man Rule, Early Ambush, Invisible Walk Test, and Passcode Follows Scope.
- Commercial Wireless Compatibility: Works with Inovonics mesh wireless technology for expanded wireless point integration.
- High-Capacity Keypad Support: Supervises up to 16 keypads or supports up to 32 unsupervised keypads.
The D7412GV3 delivers the reliability and precision required for commercial intrusion detection, fire alarm integration, and advanced facility security management systems.
