Bosch GRL4000-80CHV 18V Connected Green-Beam Rotary Laser with Dual-Axis Slope
- Regular price
- $2,085.00
- Sale price
- $2,085.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: GRL4000-80CHV
Description
The Bosch GRL4000-80CHV is an 18-volt connected green-beam rotary laser designed for precise horizontal, vertical, and dual-axis slope leveling on large-scale construction sites. This instrument projects a highly visible green laser line that extends up to 4,000 feet when paired with a laser receiver, ensuring accurate grading and layout alignment. By utilizing electronic self-leveling and remote application connectivity, the device minimizes setup time and enhances surveying efficiency in demanding outdoor environments.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Bosch |
| Category | Test & Measurement |
| Part Number | GRL4000-80CHV |
| Subcategory | Rotary Laser Levels |
| Laser Diode | Green Beam, Class 3R |
| Working Range (with Receiver) | Up to 4,000 ft Diameter |
| Accuracy | +/- 1/16 Inch at 100 ft |
| Self-Leveling Range | +/- 8.5 Degrees |
| Slope Capability | Dual-Axis (Dial-In) |
| Connectivity | Bluetooth (Bosch Leveling Remote App) |
| Power Source | Bosch 18V Lithium-Ion Battery |
| Ingress Protection Rating | IP68 (Dust and Water Resistant) |
| Mounting Thread | 5/8-11 |
| Weight | 8.6 lbs |
Information About GRL4000-80CHV
The GRL4000-80CHV is a high-visibility rotary laser level that operates on the standard Bosch 18V lithium-ion battery platform for extended jobsite runtime. It features an ultra-rugged IP68-rated composite housing designed to withstand extreme dust exposure, heavy rain, and accidental drops up to one meter. Civil engineers, concrete contractors, and land surveyors utilize this tool to establish strict elevation benchmarks, grade slopes, and align complex formwork. The system integrates Bluetooth technology to communicate directly with mobile devices, allowing operators to adjust dual-axis slope parameters remotely without physically touching the unit.
Key Features:
● Green Beam Technology: Projects a concentrated green laser line that is up to four times more visible to the human eye than standard red beams.
● Extended Working Range: Achieves accurate leveling up to a 4,000-foot diameter when operated in conjunction with a compatible laser receiver.
● Dual-Axis Slope Control: Allows operators to manually dial in precise slope angles on both the X and Y axes for complex grading applications.
● Bluetooth Connectivity: Syncs with the Bosch Leveling Remote App to enable remote adjustments, slope inputs, and tool diagnostics from a smartphone.
● 18V Battery Platform: Utilizes standard Bosch 18V lithium-ion batteries to provide extended continuous runtime during heavy-duty outdoor operations.
● IP68 Environmental Protection: Features a fully sealed enclosure that prevents water and dust ingress, ensuring operational integrity in harsh weather.
● Electronic Self-Leveling: Automatically adjusts the internal diode assembly to correct minor base unevenness and maintain an absolute level reference.
The GRL4000-80CHV delivers the reliability and precision required for exact grade setting and large-scale structural alignment in commercial construction networks.
