BPS10A | Edwards Signaling 10A Booster Power Supply, 24VDC, UL 864 Listed
- Regular price
- $715.00
- Sale price
- $715.00
- Regular price
-
$0.00
Couldn't load pickup availability
Do you need help?
Product Description P/N: BPS10A
Description
The Edwards Signaling BPS10A Booster Power Supply is a UL 864, 10th Edition listed unit designed to provide 24 VDC filtered and regulated power for fire alarm, security, and emergency communication systems. With a 10-amp capacity, it extends system signaling capability by supporting additional NACs or auxiliary power circuits. Its durable steel cabinet and built-in battery charging system make it a reliable choice for life safety applications.
Technical Specifications
| Condition | New |
| Brand | Edwards Signaling |
| Part Number | BPS10A |
| Subcategory | Booster Power Supplies |
| Series | EST3 Multiplexed Fire Alarm System |
| Product Type | Booster Power Supply |
| Voltage Output | 24 VDC filtered and regulated |
| Output Capacity | 10 Amps |
| NAC Circuits | 4 Class B (convertible to 2 Class A) |
| Circuit Capacity | 3A per circuit (not exceeding unit rating) |
| Synchronization | Genesis and Enhanced Integrity appliances |
| Input Power Options | 110 VAC or 230 VAC |
| Battery Support | Up to 2 × 10 Ah batteries |
| Cabinet Type | Lockable steel enclosure, removable door |
| Diagnostic Features | Onboard LEDs for fault and wiring issues |
| Wire Size Supported | 18–12 AWG |
| Protection | Self-restoring overcurrent protection |
| Dimensions | 14.5 × 18.3 × 5.2 in |
| Color | Red |
| Weight | 13 lbs |
Information About BPS10A
The BPS10A is part of the EST3 Multiplexed Fire Alarm System series, built to deliver dependable auxiliary and NAC power to a wide range of safety and security applications. It includes four Class B notification appliance circuits, which can be converted to two Class A circuits and activated in groups for flexible configuration. The unit supports synchronization of Genesis and Enhanced Integrity notification appliances while providing advanced diagnostics through onboard LEDs. With a lockable steel cabinet, dual battery charging capability, and compatibility with both 110V and 230V AC models, the BPS10A ensures easy integration and reliable performance in critical installations.
Key Features:
- UL 864, 10th Edition Listed: Certified for compliance with modern fire protection standards.
- 10-Amp Power Capacity: Provides regulated 24 VDC power for NACs and auxiliary loads.
- Flexible NAC Configuration: Four Class B circuits convertible to two Class A circuits.
- Genesis Appliance Synchronization: Ensures compatibility with Genesis and Enhanced Integrity devices.
- Built-in Battery Charging: Monitors and charges internal or external batteries up to 10 Ah.
- Durable Steel Enclosure: Standard Edwards keyed, lockable cabinet with removable door.
- Diagnostic LEDs: Simplifies troubleshooting by identifying wiring or internal faults.
- Optional Enhancements: Supports tamper switch and OSHPD seismic pre-approval.
The BPS10A delivers the reliability and precision required for expanding and powering modern fire alarm and life safety systems.
