BR220220 | Eaton Type BQ 4-Pole 20A 120/240V Plug-On Thermal Magnetic Quad Circuit Breaker
- Regular price
- $167.00
- Sale price
- $167.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: BR220220
Description
The Eaton BR220220 is a quad-style molded case circuit breaker designed for Type BR load centers requiring compact multi-pole protection. Rated at 120/240 volts and 20 amps per pole, it provides dependable overcurrent protection across four independent circuits. Its plug-on CTL design with rejection tab ensures secure panel fit and proper breaker placement.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Eaton |
| Category | Circuit Breaker |
| Part Number | BR220220 |
| Voltage Rating | 120/240 V |
| Amperage Rating | 20 A per pole |
| Amp Rating | 20A |
| Pole Configuration | Quad (Four-Pole) |
| Breaker Style | Plug-In |
| Type | Type BQ / Type BR Loadcenters |
| Protection | Thermal Magnetic |
| AIC Rating | 10 kAIC |
| Wire Size | #14–4 AWG Cu/Al |
| Dimensions | 3 in L × 2 in W × 3.13 in H |
| Application | Residential/commercial multi-circuit protection |
Information About BR220220
The BR220220 is part of Eaton’s BQ quad breaker series designed for Type BR load centers, offering four independent 20-amp circuits within a compact 1-inch wide format. Its plug-on CTL construction includes a rejection tab to prevent misapplication in non-CTL panels, ensuring safe and correct installation. This quad breaker is well suited for applications where panel space is limited but multiple circuits are required, making it a practical solution for residential and commercial upgrades. With thermal magnetic protection, it provides dependable long-time overload and instantaneous short-circuit response across all poles.
Key Features
- Quad configuration: Provides four independent 20-amp circuits in a compact form factor.
- Plug-on CTL design: Ensures proper installation with rejection tab compatibility.
- Thermal magnetic protection: Delivers reliable overload and instantaneous fault response.
- 10 kAIC interrupt rating: Supports standard residential and commercial fault-clearing requirements.
- Type BQ for BR load centers: Ensures compatibility with Eaton Type BR panels.
- Space-saving construction: Allows multiple circuits to be added without expanding the panel.
- Supports Cu/Al conductors: Accepts #14–4 AWG for wiring flexibility.
- Durable molded case: Built for long-term performance in home and commercial environments.
The BR220220 delivers the reliability and precision required for multi-circuit protection while maximizing space efficiency in Type BR load centers.
