BWH2200 | Eaton Cutler-Hammer BWH Series Main Circuit Breaker 200A 2-Pole 120/240V 25 kAIC
- Regular price
- $565.00
- Sale price
- $565.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: BWH2200
Description
The Eaton Cutler-Hammer BWH2200 is a main molded case circuit breaker designed for dependable overcurrent protection in single-phase electrical distribution systems. This two-pole breaker is rated at 200 A and operates at 120/240 V with a thermal-magnetic trip mechanism.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Eaton Cutler-Hammer |
| Category | Molded Case Circuit Breaker |
| Part Number | BWH2200 |
| Subcategory | Molded Case / 2-Pole |
| Series / Family | BWH Series |
| Breaker Type | BWH |
| Number of Poles | 2 |
| Amperage Rating | 200 A |
| Voltage Rating | 120/240 V |
| Phase | 1 |
| Trip Unit Type | Thermal-Magnetic |
| Protection Functions | LI – Long-Time and Instantaneous |
| Interrupt Rating | 25 kA at 240 V |
| Connection Type | Bolt-On |
| Compatible Wire Sizes | #2 AWG to 300 kcmil (Cu/Al) |
| Application | Main Circuit Breaker |
Information About BWH2200
The BWH2200 is part of Eaton’s Cutler-Hammer BWH series, engineered to serve as a main breaker in electrical distribution equipment. It is designed for use in single-phase systems requiring reliable main overcurrent protection and high interrupting capacity. The breaker incorporates thermal sensing for sustained overloads and magnetic sensing for instantaneous short-circuit conditions. Its bolt-on design provides secure mounting and stable electrical contact in compatible enclosures and meter-main assemblies.
Key Features:
- BWH Series Main Breaker Design: Developed for use as a primary disconnect in residential and light commercial systems.
- Thermal-Magnetic Protection: Combines long-time overload protection with instantaneous short-circuit interruption.
- 200 Amp Current Rating: Suitable for main service and feeder applications.
- Two-Pole Configuration: Supports 120/240 V single-phase electrical systems.
- High Interrupting Capacity: Rated at 25 kA to safely interrupt high fault currents.
- Wide Conductor Compatibility: Accepts copper or aluminum conductors from #2 AWG to 300 kcmil.
- Bolt-On Installation: Ensures secure mechanical and electrical connection within compatible Eaton equipment.
The BWH2200 delivers the reliability and precision required for effective main circuit protection in Eaton Cutler-Hammer BWH series electrical distribution systems.
