Part #: BX-HSIO1 Manufactured by: Automation Direct
Regular price
$547.00
Sale price
$547.00
Regular price
1 in Stock
Condition: New-Surplus Original Box
Shipping calculated at checkout.
Product Overview
The AutomationDirect BX-HSIO1 is a high-speed pulse combo module for BRX Series PLCs, designed for precise motion control ...  Read more
We accept:
  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Venmo
  • Visa
warranty
IQElectro 2-Year Warranty
Warranty for Product #: BX-HSIO1
IQElectro offers a free 2-year warranty on all products. You can trust that every purchase is a reliable investment in the future of your company. Warranty Terms
2-3 Day Free Shipping
Packed Ready to Ship
24/7 Expert Support
Return within 30-Days
IQElectro LLC BBB Business Review
IQElectro is Not an authorized distributor for Automation Direct
Original Manufacturer's Warranty Not Covered, This Product is SURPLUS.

Product Description P/N: BX-HSIO1

Description / Specifications

Description

The Automation Direct BX-HSIO1 is a high-speed pulse combo module designed for BRX Series PLCs, offering precise pulse input and output control. It features 4 high-speed inputs and 2 high-speed outputs, supporting pulse train, PWM, and frequency modes for motion control applications.





Technical Specifications

Condition New/Never Used Surplus
Brand Automation Direct
Category PLCs and Accessories
Part Number BX-HSIO1
Subcategory
PLC Expansion Modules
Weight
0.91 kgs
Maximum Switching Frequency 250 kHz
Number of High-Speed Capable Input Points
8
Nominal Input Voltage 12-24 VDC
Discrete Input Type Sinking/sourcing
Number of Non-Isolated Input Commons
2
Number of Isolated Input Commons
2
Number of Input Channels
8
Number of High-Speed Capable Output Points
8
Nominal Output Voltage 12-24 VDC
Discrete Output Type Sinking
Number of Non-Isolated Output Commons 2
Number of Isolated Output Commons 2
Load Current 0.5A/point





Information About BX-HSIO1

The AutomationDirect BX-HSIO1 is a high-speed pulse combo module designed for the BRX Series Programmable Logic Controllers (PLCs). This module enhances the BRX PLC's capabilities by providing precise control over high-speed inputs and outputs, making it ideal for applications requiring rapid and accurate signal processing.

Key Specifications:

  • Input Specifications:

    • Number of Inputs: 8 high-speed input points
    • Input Type: Sinking/Sourcing (NPN/PNP)
    • Voltage Range: 9–30 VDC
    • Maximum Switching Frequency: 250 kHz
    • Input Functions: Counting, scaling, measurement, interrupts, programmable limit switches (PLS), and table-driven inputs
  • Output Specifications:

    • Number of Outputs: 8 high-speed output points
    • Output Type: Sinking (NPN)
    • Voltage Range: 5–36 VDC
    • Maximum Load Current: 0.5 A per output
    • Maximum Switching Frequency: 250 kHz
    • Output Functions: Pulse Train Output (PTO), Pulse Width Modulation (PWM), positioning, velocity control, electronic gearing, camming, following, homing, and jogging

Key Features:

  • High-Speed Performance: Supports input and output signals up to 250 kHz, ensuring rapid response for time-critical applications.
  • Versatile Input/Output Configuration: Offers flexible input and output options, accommodating various industrial sensors and actuators.
  • Advanced Motion Control: Enables complex motion profiles, including electronic camming and gearing, suitable for precision automation tasks.
  • Robust Design: Engineered for reliable operation in industrial environments, ensuring consistent performance under demanding conditions.

Applications:

  • Motion Control Systems: Ideal for controlling stepper and servo motors in applications requiring precise positioning and speed regulation.
  • High-Speed Counting: Suitable for processes that involve rapid counting of items or events, such as packaging lines and assembly systems.
  • Pulse Generation: Generates accurate pulse signals for driving external devices like frequency inverters and other pulse-responsive equipment.
  • Industrial Automation: Enhances automation systems with high-speed I/O requirements, improving overall system efficiency and responsiveness.
IQElectro is not an authorized distributor.
QElectro LLC (IQElectro) is NOT an Authorized Distributor or in any way affiliated with Rockwell Automation, Siemens, or any other Manufacturers. IQElectro is NOT an Authorized Dealer of this product. The product may be of older version, date codes, or design than that available from authorized dealers. As IQElectro is not an authorized dealer of this product, the Original Manufacturer's Warranty and Support DO NOT apply. IQElectro sells SURPLUS only and DOES NOT SELL SOFTWARE or FIRMWARE licenses For more detailed information, please refer to the full version of our disclaimer policy Disclaimer Policy.
