C147094P02 | Trane 24V 30A Single-Pole HVAC Relay Contactor
- Regular price
- $55.00
- Sale price
- $55.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: C147094P02
Description
The Trane C147094P02 is a 24-volt single-pole relay contactor designed to control electrical loads in HVAC systems. Rated for 30 amps, it supports reliable switching of compressors, fans, and other equipment. The C147094P02 ensures stable circuit control and dependable operation across standard heating and cooling applications.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Trane |
| Category | Panel Accessories |
| Part Number | C147094P02 |
| Subcategory | Relay/Socket |
| Poles | 1 pole |
| Amperage Rating | 30A |
| Control Voltage | 24 VAC |
| Device Type | Relay contactor |
| Primary Application | HVAC compressors and fan motors |
| Coil Type | Low-voltage AC control |
| Mounting Style | Panel or equipment-mounted |
| Load Compatibility | Heating and cooling system components |
| Construction | Heavy-duty contacts with insulated frame |
| Operation | Electrical switching for HVAC circuits |
| Use Case | Residential and light commercial HVAC systems |
Information About C147094P02
The C147094P02 is part of Trane’s line of HVAC relay contactors engineered to manage electrical circuits in residential and light commercial systems. It features a durable coil and contact assembly designed for consistent performance when operating on a 24-volt control signal. The single-pole design allows straightforward integration into air handlers, condensers, and packaged units using standard wiring practices. Commonly applied in compressor and fan motor control, the contactor supports stable switching under varying load conditions, contributing to reliable system operation.
Key Features:
- Single-pole configuration: Provides straightforward load switching for HVAC components.
- 30-amp rating: Supports compressors, blowers, and auxiliary HVAC loads.
- 24V control coil: Compatible with standard thermostat and control board outputs.
- Durable contact assembly: Ensures long-term switching performance.
- HVAC-ready design: Fits common Trane system layouts and mounting arrangements.
- Stable electrical performance: Designed for repeated cycling in demanding environments.
- Easy installation: Supports quick replacement during service or upgrades.
- Versatile application: Suitable for heating and cooling circuits.
The C147094P02 delivers the reliability and precision required for dependable electrical switching in HVAC power circuits.
