Product Description P/N: C9900-P224
Description
The Beckhoff C9900-P224 is a compact industrial power supply module designed to provide dual 5 VDC and 12 VDC regulated outputs for Beckhoff automation systems. Operating from a 22–30 VDC input, it delivers up to 20 A total output current, ensuring stable power for control units and peripherals.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Beckhoff |
| Category | Industrial Automation |
| Part Number | C9900-P224 |
| Subcategory | Power Supply Module |
| Input Voltage Range | 22–30 V DC |
| Input Current | 15 A max |
| Output Voltage 1 | 5 V DC |
| Output Voltage 2 | 12 V DC |
| Total Output Current | 20 A max |
| Power Type | Regulated DC power supply |
| Protection Features | Overload and short-circuit protection (typical for Beckhoff PSUs) |
| Cooling Method | Passive convection |
| Efficiency | High-efficiency DC-DC conversion (design optimized for Beckhoff IPCs) |
| Connection Type | Industrial terminal connectors |
| Operating Temperature | 0°C to +55°C (typical for Beckhoff PSUs) |
| Storage Temperature | -25°C to +85°C |
| Relative Humidity | Up to 95%, non-condensing |
| Mounting Type | Internal module integration or DIN-rail installation |
| Protection Rating | IP20 |
| Approvals | CE, UL (depending on configuration) |
| Weight | 0.26 lbs (approx. 118 g) |
Information About C9900-P224
The C9900-P224 is part of Beckhoff’s modular power supply lineup, providing reliable low-voltage DC output for embedded control, IPC, and I/O systems. It converts 22–30 VDC input to stabilized 5 VDC and 12 VDC outputs, suitable for powering controllers, logic circuits, and communication interfaces. Engineered for efficiency and compact integration, the unit ensures consistent voltage regulation even under variable industrial load conditions. The module’s lightweight, IP20-rated housing supports both internal installation and DIN-rail mounting, making it ideal for compact control cabinets or embedded environments where stable DC distribution is essential.
Key Features:
- Dual Voltage Output: Provides both 5 VDC and 12 VDC regulated outputs for system logic and peripheral power supply.
- High Current Capacity: Delivers up to 20 A combined output for reliable operation of multiple control modules.
- Wide Input Range: Operates from 22–30 VDC, suitable for standard industrial DC bus systems.
- Compact and Lightweight Design: Weighs just 0.26 lbs, simplifying installation and minimizing space requirements.
- Integrated Protection: Designed with overload and short-circuit protection for safe, maintenance-free use.
- Efficient Power Conversion: Ensures stable voltage delivery with minimal heat generation through optimized DC-DC design.
- Flexible Installation Options: Can be mounted within Beckhoff control systems or on DIN rails for standalone applications.
- Industrial Reliability: Built for long-term operation under demanding industrial conditions with CE/UL compliance.
The C9900-P224 delivers the reliability and precision required for power distribution in Beckhoff control systems, embedded PCs, and automation platforms.
Description
The Beckhoff C9900-P224 is a compact industrial power supply module designed to provide dual 5 VDC and 12 VDC regulated outputs for Beckhoff automation systems. Operating from a 22–30 VDC input, it delivers up to 20 A total output current, ensuring stable power for control units and peripherals.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Beckhoff |
| Category | Industrial Automation |
| Part Number | C9900-P224 |
| Subcategory | Power Supply Module |
| Input Voltage Range | 22–30 V DC |
| Input Current | 15 A max |
| Output Voltage 1 | 5 V DC |
| Output Voltage 2 | 12 V DC |
| Total Output Current | 20 A max |
| Power Type | Regulated DC power supply |
| Protection Features | Overload and short-circuit protection (typical for Beckhoff PSUs) |
| Cooling Method | Passive convection |
| Efficiency | High-efficiency DC-DC conversion (design optimized for Beckhoff IPCs) |
| Connection Type | Industrial terminal connectors |
| Operating Temperature | 0°C to +55°C (typical for Beckhoff PSUs) |
| Storage Temperature | -25°C to +85°C |
| Relative Humidity | Up to 95%, non-condensing |
| Mounting Type | Internal module integration or DIN-rail installation |
| Protection Rating | IP20 |
| Approvals | CE, UL (depending on configuration) |
| Weight | 0.26 lbs (approx. 118 g) |
Information About C9900-P224
The C9900-P224 is part of Beckhoff’s modular power supply lineup, providing reliable low-voltage DC output for embedded control, IPC, and I/O systems. It converts 22–30 VDC input to stabilized 5 VDC and 12 VDC outputs, suitable for powering controllers, logic circuits, and communication interfaces. Engineered for efficiency and compact integration, the unit ensures consistent voltage regulation even under variable industrial load conditions. The module’s lightweight, IP20-rated housing supports both internal installation and DIN-rail mounting, making it ideal for compact control cabinets or embedded environments where stable DC distribution is essential.
Key Features:
- Dual Voltage Output: Provides both 5 VDC and 12 VDC regulated outputs for system logic and peripheral power supply.
- High Current Capacity: Delivers up to 20 A combined output for reliable operation of multiple control modules.
- Wide Input Range: Operates from 22–30 VDC, suitable for standard industrial DC bus systems.
- Compact and Lightweight Design: Weighs just 0.26 lbs, simplifying installation and minimizing space requirements.
- Integrated Protection: Designed with overload and short-circuit protection for safe, maintenance-free use.
- Efficient Power Conversion: Ensures stable voltage delivery with minimal heat generation through optimized DC-DC design.
- Flexible Installation Options: Can be mounted within Beckhoff control systems or on DIN rails for standalone applications.
- Industrial Reliability: Built for long-term operation under demanding industrial conditions with CE/UL compliance.
The C9900-P224 delivers the reliability and precision required for power distribution in Beckhoff control systems, embedded PCs, and automation platforms.
