Carrier OPN-APP i-Vu General Purpose BACnet HVAC AppController
- Regular price
- $825.00
- Sale price
- $825.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: OPN-APP
Description
The Carrier OPN-APP (General Purpose AppController) is a programmable native BACnet building automation controller engineered to monitor, regulate, and optimize commercial HVAC equipment. Pre-engineered with factory control programs, it manages single-purpose terminal equipment such as fan coils, unit ventilators, water source heat pumps, and constant volume air handling units. It provides standalone control capabilities and features plug-and-play integration with the Carrier i-Vu Building Automation System.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Carrier |
| Category | HVAC Controls / Building Automation |
| Part Number | OPN-APP |
| Subcategory | General Purpose AppController |
| Device Type | Programmable BACnet HVAC Controller |
| I/O Capacity | 14 Total Points (6 Universal Inputs, 5 Binary Outputs, 3 Analog Outputs) |
| Communication Protocol | Native BACnet MS/TP |
| System Compatibility | Carrier i-Vu Building Automation System |
| Power Supply | Class 2 24 Vac Source |
| Enclosure / Mounting | Control Cabinet Enclosed Panel Mount |
| Weight | 1.50 lbs |
Information About OPN-APP
Designed for seamless deployment in modern commercial facilities, the OPN-APP features a robust hardware architecture equipped with 14 native I/O points (5 binary outputs, 6 universal inputs, and 3 analog outputs). Weighing approximately 0.68 kgs (1.5 lbs), it features a compact design for secure panel mounting, removable screw terminals for straightforward wiring, a battery-backed real-time clock, and diagnostic status LEDs. It supports native BACnet MS/TP communications, communicating room sensors, and local operator displays.
Key Features:
-
Factory-Engineered Programs: Pre-programmed software options optimize performance for fan coils, heat pumps,unit ventilators, and air handlers.
-
Native BACnet MS/TP Communications: Integrates effortlessly into building management architectures supporting standard open protocols.
-
Comprehensive I/O Capacity: Features 14 standalone input/output points consisting of 6 universal inputs, 5 binary outputs, and 3 analog outputs.
-
i-Vu System Plug-and-Play: Fully compatible with the Carrier i-Vu Building Automation System for centralized monitoring and scheduling.
-
Battery-Backed Real-Time Clock: Retains schedules, trends, and configuration parameters during power failures via a lithium CR2032 coin cell.
-
Local Sensor Compatibility: Supports Carrier communicating room sensors (up to 10 wireless/ZS sensors) for zone-level setpoint adjustments and overrides.
-
Built-in Visual Diagnostics: Equipped with explicit status LED indicators for processor status, run conditions,errors, and network communication.
-
Robust Enclosure Protection: Built-in surge and transient protection complying with EN61000-6-1 standards for heavy industrial operational safety.
The OPN-APP delivers the processing power, reliability, and network flexibility required for advanced commercial HVAC climate control and automated terminal equipment management.
