CC-PAIL51 | Honeywell Low-Level Analog Input Module
- Regular price
- $4,260.00
- Sale price
- $4,260.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: CC-PAIL51
Description
The Honeywell CC-PAIL51 is a 16-channel low-level analog input module designed for precise temperature measurements in industrial environments. It supports both thermocouple and RTD inputs, ensuring accurate data acquisition for process control systems.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | Honeywell |
| Category |
Input Modules
|
| Part Number | CC-PAIL51 |
| Subcategory | Low-Level Analog Input Modules |
| Input Channels | 16 fully isolated channels |
| Input Types | Thermocouple (TC) and Resistance Temperature Detector (RTD) |
| Nominal Input Range (TC) | -20 to +100 millivolts |
| Max Normal Mode Input (TC) | -10 to +10 volts |
| Max Normal Mode Input (RTD) | -1 to +2 volts @ 100 milliamps |
| Input Impedance (TC) | 1 megohm at DC |
| Gain Error | 0.050% full scale max |
| Long-Term Drift | 500 ppm |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Input Scan Rate | 1 second |
| Channel Bandwidth | 0 to 4.7 Hz (-3 dB) |
| Cold Junction Compensation Range | -20°C to +60°C (±0.5°C typical) |
| Supported Thermocouple Types | ANSI J, K, E, T, B, S, R |
| Weight | 0.35 kg (0.77 lbs) |
Information About CC-PAIL51
The CC-PAIL51 is a low-level analog input module compatible with Honeywell's Experion Series C I/O system. It accepts up to 16 channels of temperature inputs from RTD and thermocouple sensors, providing flexibility in temperature measurement applications. Each channel is fully isolated, enhancing signal integrity and system reliability. The module integrates seamlessly with the CC-TAIL51 IOTA for non-redundant configurations, eliminating the need for external process manager FTAs.
Key Features:
- 16-Channel Input: Supports up to 16 fully isolated channels for temperature measurement.
- Sensor Compatibility: Accepts both thermocouple (TC) and resistance temperature detector (RTD) inputs.
- High Accuracy: Offers a gain error of 0.050% full scale max and long-term drift of 500 ppm.
- Cold Junction Compensation: Provides cold junction compensation for accurate thermocouple readings.
- Open Thermocouple Detection: Features configurable open thermocouple detection to ensure data integrity.
- Wide Operating Temperature: Operates effectively in environments ranging from -40°C to +70°C.
- Robust Isolation: Ensures channel-to-channel and channel-to-power system isolation for enhanced safety.
- Seamless Integration: Designed to integrate with Honeywell's Experion Series C I/O system without external FTAs.
The CC-PAIL51 delivers the reliability and precision required for accurate temperature measurements in industrial automation and process control applications.
