CCV2125 | Eaton CCV Tenant Main Breaker
- Regular price
- $385.00
- Sale price
- $385.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: CCV2125
Description
The CCV2125 is an Eaton Type CCV Tenant Main Circuit Breaker designed for tenant main circuit protection. It features a current rating of 125 amperes with an interrupting capacity of 10 kiloamperes. This breaker is configured as a two-pole unit and operates at 120/240 volts. It accommodates wire sizes ranging from #2/0 AWG to 300 kcmil for both copper and aluminum conductors. Enclosed within a Type ECC unit enclosure, the CCV2125 ensures reliable and compliant circuit protection for various applications.
Technical Specifications
|
Part Number |
CCV2125 |
|
Manufacturer |
Eaton Cutler-Hammer |
|
Family |
Tenant Main |
|
Poles |
2 |
|
Amps |
125 |
|
Volts |
240 |
|
Phase |
1 |
|
Category |
Molded Case / 2-Pole |
|
Connection |
Feed Thru |
|
Type |
CCV |
|
Functions |
LI - Long-Time and Instantaneous Trip |
|
Protection |
Thermal Magnetic |
|
AIC Rating |
10kA@240V |
Information About CCV2125
The CCV2125 is a main circuit breaker manufactured by Eaton, specifically categorized as a Type CCV Tenant Main Circuit Breaker. It is engineered to serve as the primary circuit protection device for tenant main circuits. With a current rating of 125 amperes, the CCV2125 is designed to handle electrical loads up to this specified limit.
In terms of its interrupting capacity, the CCV2125 is rated at 10 kiloamperes (10 kAIC), indicating its ability to safely interrupt fault currents under normal operating conditions. This ensures reliable protection against overcurrent situations that may arise within the electrical system.
Configured as a two-pole unit, the CCV2125 operates within a voltage range of 120/240 volts, making it suitable for a variety of electrical installations. Its compatibility with different voltage levels enhances its versatility and applicability across various residential, commercial, and industrial settings.
Manufacturer information
Eaton Corporation is a multinational power management company offering a diverse range of electrical, hydraulic, and aerospace solutions. Known for innovation, Eaton serves customers in various industries worldwide.
