LOYTEC LIP-3ECTB-CEAG CG-S/IP CEA-709 IP-852 Ethernet Networking Router
- Regular price
- $599.00
- Sale price
- $599.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: LIP-3ECTB-CEAG
Description
The CEAG LIP-3ECTB-CEAG is a CG-S/IP network router based on LOYTEC L-IP technology and designed to connect field-level CEA-709 networks with Ethernet-based IP communication. Identified by CEAG part number 40071347590, the unit provides TP/FT-10 and Ethernet connectivity for network communication within centralized emergency lighting and building control installations.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | CEAG / LOYTEC |
| Category | Computer |
| Part Number | LIP-3ECTB-CEAG |
| Subcategory | Networking Router |
| CEAG Part Number | 40071347590 |
| Product Type | CG-S/IP Network Router |
| Router Technology | CEA-709 / IP-852 |
| Fieldbus Interface | 1 × TP/FT-10 |
| Ethernet Interface | 1 × 100Base-T Ethernet Port |
| Configuration Server | CEA-852 Configuration Server, up to 100 members |
| Power Supply | 12–35 volts direct current / 12–24 volts alternating current ±10% |
| Typical Power Consumption | 3 watts |
| Configuration | Web Browser or Serial Console |
| Installation | DIN Rail Mounting |
| Operating Temperature | 0°C to 50°C |
| Protection Rating | IP40 Enclosure / IP20 Terminals |
| Dimensions | 107 × 100 × 60 mm |
| Weight | 0.64 lbs |
Information About LIP-3ECTB-CEAG
The LIP-3ECTB-CEAG is a CEAG-specific version of the LOYTEC L-IP CEA-709/IP-852 router used as a CG-S/IP communication device in networked control systems. The hardware platform combines one TP/FT-10 fieldbus interface with one 100Base-T Ethernet interface and supports routing of CEA-709 communication over IP-852 Ethernet networks. Its architecture supports configured router, smart switch, and repeater operating modes, while an integrated CEA-852 configuration server can manage up to 100 members on an IP-852 channel. The DIN rail-mounted unit is intended for permanent installation in control cabinets where CEAG CG-S equipment and related network components require communication over Ethernet infrastructure.
Key Features:
- CG-S/IP Network Routing: Provides a communication path between CEAG control infrastructure and Ethernet-based networks using the LOYTEC L-IP platform.
- CEA-709/IP-852 Technology: Routes CEA-709 network packets across Internet Protocol infrastructure using the IP-852 communication standard.
- TP/FT-10 Interface: Includes one TP/FT-10 port for connection to compatible field-level network devices.
- Ethernet Connectivity: Provides one 100Base-T Ethernet interface for IP-852 communication and network management.
- Multiple Router Modes: Supports configured router, smart switch, smart switch with subnet learning, and repeater operating modes.
- Integrated Configuration Server: Incorporates a CEA-852 configuration server supporting up to 100 members on an IP-852 channel.
- Flexible Power Input: Operates from 12–35 volts direct current or 12–24 volts alternating current with typical consumption of approximately 3 watts.
- Web-Based Configuration: Supports setup and network management through a web browser, with a serial console available for configuration and diagnostics.
The LIP-3ECTB-CEAG delivers the reliability and precision required for CEAG control network routing, CEA-709 communication, and Ethernet-based system integration.
