CH2150 | Eaton CH Thermal Magnetic Circuit Breaker 150A Four-Pole 120/240V 10kAIC
- Regular price
- $950.00
- Sale price
- $950.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: CH2150
Description
The Eaton CH2150 is a Type CH thermal magnetic circuit breaker rated at 150 amps for overcurrent protection in 120/240 volt electrical systems. Designed as a four-pole breaker, part number CH2150 is intended for installation in Eaton Type CH loadcenters and supports common trip operation.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Eaton |
| Category | Circuit Breaker |
| Part Number | CH2150 |
| Subcategory | Load Center Circuit Breaker |
| Ampere Rating | 150 A |
| Voltage Rating | 120/240 V |
| Number of Poles | Four-pole |
| Interrupt Rating | 10 kAIC |
| Circuit Breaker Type | CH |
| Trip Type | Common breaker trip |
| Main Circuit Breaker | CH |
| Used With | Type CH Loadcenters |
| Wire Size | #3/0 AWG Cu/Al |
| Certifications | UL 489 Type |
| Product Length / Depth | 4.5 in |
| Product Height | 3 in |
| Product Width | 3 in |
| Product Weight | 1 lb |
Information About CH2150
The CH2150 is an Eaton CH series thermal magnetic circuit breaker developed for high-capacity load center applications. It features a compact 3/4-inch Type CH form factor with four-pole construction to support multi-pole circuit protection. The breaker is engineered for seamless integration into Eaton Type CH loadcenters and supports both copper and aluminum conductors. Typical applications include residential, commercial, and light industrial systems where coordinated multi-pole tripping and dependable overcurrent protection are required.
Key Features
- Type CH Breaker Design: Built to Eaton CH specifications for compatibility with Type CH loadcenters.
- 150 Amp Current Rating: Supports high-load applications requiring stable overcurrent protection.
- Four-Pole Configuration: Enables coordinated protection across multiple phases or circuits.
- Common Trip Mechanism: Ensures all poles trip simultaneously during fault conditions.
- Thermal Magnetic Protection: Combines overload protection with instantaneous short-circuit response.
- 10 kAIC Interrupt Rating: Safely interrupts fault currents up to 10,000 amperes.
- Cu/Al Conductor Support: Accepts #3/0 AWG copper or aluminum wiring for installation flexibility.
The CH2150 delivers the reliability and precision required for multi-pole overcurrent protection in Eaton CH loadcenter applications.
