CHH2150 | Eaton 150A 2-Pole 240V CHH Series Bolt-On Thermal Magnetic Molded Case Circuit Breaker
- Regular price
- $1,419.00
- Sale price
- $1,419.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: CHH2150
Description
The Eaton CHH2150 is a 2-pole thermal magnetic molded case circuit breaker designed to provide dependable circuit protection for residential, commercial, and light industrial power systems. With a 150-amp current rating and a 240 VAC voltage capacity, it effectively safeguards electrical circuits from overloads and short circuits. Featuring an interrupting capacity of 100 kAIC at 240 V, the CHH2150 ensures high fault-clearing performance and reliability in demanding electrical environments.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Eaton |
| Category | Circuit Breakers |
| Part Number | CHH2150 |
| Subcategory | Molded Case Circuit Breakers |
| Series | CHH |
| Frame Type | CH Frame |
| Amperage Rating | 150 A |
| Voltage Rating | 240 VAC |
| Interrupting Rating | 100 kAIC @ 240 V |
| Trip Type | Thermal Magnetic |
| Functions | Long-Time and Instantaneous Trip |
| Number of Poles | 2 |
| Mounting Type | Bolt-On |
| Connection Type | Feed-Thru |
| Terminal Type | Line and Load Lugs |
| Used With | Type CH Load Centers |
| Certifications | UL 489, CSA Approved |
| Phase | Single Phase |
| Temperature Rating | 40°C |
| Dimensions (HxWxD) | 9 in x 5.5 in x 4.5 in |
| Warranty | Limited Lifetime |
| Weight | 4.5 lb |
Information About CHH2150
The CHH2150 is part of Eaton’s CHH Series of bolt-on molded case circuit breakers, known for their high interrupting ratings and robust construction. Designed for use with Type CH load centers, this breaker employs a feed-thru connection with line and load side lugs for efficient installation and secure electrical contact. Its thermal magnetic trip unit provides both long-time and instantaneous protection functions, allowing precise response to overload and short-circuit events. Engineered to meet UL 489 and CSA standards, the CHH2150 offers durable, high-capacity performance suitable for residential and commercial distribution panels.
Key Features:
- Amperage Rating: 150A current capacity ensures stable operation for medium-load circuits.
- Voltage Rating: Rated for 240 VAC for residential and light commercial use.
- Interrupting Capacity: High fault current stable operation for medium-load circuits.
- Voltage Rating: Rated for 240 VAC for residential and light commercial use.
- Interrupting Capacity: High fault current handling at 100 kAIC @ 240 V for superior protection.
- Trip Type: Thermal magnetic trip provides both long-time and instantaneous circuit protection.
- Mounting Type: Bolt-on design allows fast and secure panel installation.
- Connection Type: Feed-thru terminals with line and load lugs for simplified wiring.
- Series Compatibility: Fits Type CH load centers and CHH Series applications.
- Certifications: UL 489 and CSA approved for compliance with safety and performance standards.
The CHH2150 delivers the reliability and precision required for safe power distribution and effective circuit protection in residential and commercial electrical systems.
