CIMR-J7AZ42P2 | Omron Frequency Inverter Drive 2.2KW
- Regular price
- $699.00
- Sale price
- $699.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: CIMR-J7AZ42P2
Description
The CIMR-J7AZ42P2 is a 2.2 kW three-phase frequency inverter designed for precision motor control in compact industrial systems. It supports digital operation with potentiometer input and features a robust sine wave PWM control method for smooth performance.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | Omron |
| Category |
Drives
|
| Part Number | CIMR-J7AZ42P2 |
| Subcategory | Drive |
| Series | CIMR |
| Product Type | Frequency Inverter |
| Operator | Digital with potentiometer |
| Input Voltage | 380 to 460 VAC |
| Input Phase | Three phase |
| Maximum Motor Output | 2.2 kW |
| Inverter Capacity | 4.2 kVA |
| Output Current | 5.5 Amps |
| Maximum Output Frequency | 400 Hz |
| Maximum Output Voltage | 380 to 460 VAC |
| Control Method | Sine wave PWM |
| Overload Capacity | 150% of rated current for 1 min |
| Operating Temperature | -10 to 50 °C |
| Enclosure | Open chassis |
| Storage Temperature | -20 to 60 °C |
| Maximum Altitude | 1000 m |
| Weight | 10.00 lbs |
Information About CIMR-J7AZ42P2
The CIMR-J7AZ42P2 belongs to the CIMR J7 Series by Omron and is a compact, open-chassis frequency inverter built for general-purpose motor control. Operating from a three-phase 380 to 460 VAC input, it delivers a 2.2 kW motor output with an inverter capacity of 4.2 kVA. This model offers intuitive digital control with potentiometer adjustment, enabling quick setup and speed variation in simple drives. The output current reaches 5.5 A, and the unit supports up to 400 Hz output frequency, making it suitable for fans, pumps, and conveyors. With a 150% overload capacity for 1 minute, it provides resilience for brief load surges. Its open-frame design supports installations in controlled environments, and the rated operating temperature range is –10 °C to 50 °C with reliable operation up to 1000 meters altitude.
Key Features:
- Wide Input Voltage Range: Operates from 380 to 460 VAC three-phase input, compatible with standard industrial power sources across regions.
- Efficient Motor Control: Supports up to 2.2 kW motor output and 4.2 kVA inverter capacity, delivering 5.5 A of smooth, controlled current.
- Flexible Frequency Output: Provides output frequencies up to 400 Hz, ideal for variable-speed control of motors in process and machine automation.
- Sine Wave PWM Control Method: Ensures quiet, efficient operation with reduced harmonic distortion and improved motor protection.
- User-Friendly Digital Interface: Equipped with a potentiometer and digital operator for simple configuration and real-time adjustments.
- High Overload Capability: Delivers 150% of rated current for 1 minute, enabling startup under load and resistance to short-term overcurrents.
- Open Chassis Design: Offers a lightweight, compact form factor suitable for enclosed panel installations or integration into OEM systems.
- Wide Temperature Range: Reliable in temperatures from –10 °C to +50 °C and storage down to –20 °C, suitable for diverse industrial environments.
The CIMR-J7AZ42P2 delivers compact, reliable motor control with flexible programming and robust performance in a wide range of automation scenarios.
