CIMR-V7AT45P5 | Yaskawa Electric Frequency Converter 606V7 5.5KW 400V
- Regular price
- $852.00
- Sale price
- $852.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: CIMR-V7AT45P5
Description
The CIMR‑V7AT45P5 is a compact AC inverter designed to deliver up to 5.5 kW of motor output power in industrial control applications. It offers flexible three‑phase 380–460 VAC input and stepless speed regulation up to 460 V and 400 Hz. Built for reliability in environments such as conveyors, machine tools, pumps, and packaging systems.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | Yaskawa |
| Category |
Industrial AC Drives
|
| Part Number | CIMR-V7AT45P5 |
| Subcategory | General‑Purpose Inverter |
| Series | V7 (Digital AC Drive) |
| Power Output | 5.5 kW (≈11 kVA) |
| Rated Current | 14.8 A |
| Input Voltage | 3‑phase 380–480 VAC, 50/60 Hz |
| Output Voltage | Adjustable 0–460 VAC |
| Output Frequency | 0–400 Hz |
| Control Modes | V/f, open-loop vector |
| Operator Type | Built‑in digital operator with potentiometer |
| Cooling Method | Internal air cooling |
| Frame Size (booksize) | 15.2 × 48.3 × 26.7 cm |
| Technology | Compact legacy drive with analog/vector control |
| Enclosure Rating | NEMA 1 / IP20 (booksize design) |
| Usage Context |
Conveyor, pump, blower, packaging, etc. |
| Weight | 10.7 kg |
Information About CIMR-V7AT45P5
The CIMR‑V7AT45P5 is part of Yaskawa’s legacy V7 series of digital AC drives. This model delivers a 5.5 kW (≈11 kVA) rating with continuous output current up to 14.8 A and supports vector or V/f open-loop control. It features a digital operator with potentiometer adjustment (Asian standards variant) and built‑in internal air cooling. Compatible with three‑phase 380–480 VAC input and capable of delivering variable three‑phase 0–460 VAC at up to 400 Hz output frequency. Though a legacy product no longer actively promoted in the Americas, it remains in use where cost‑effective vector control is needed.
Key Features:
- Power Rating: 5.5 kW continuous output delivering approximately 11 kVA capacity.
- Input Voltage Range: Compatible with 3-phase 380–480 VAC at 50/60 Hz.
- Output Capability: Delivers up to 460 VAC at frequencies up to 400 Hz and 14.8 A.
- Control Modes: Supports V/f control and open‑loop vector mode for higher torque at low speed.
- Digital Operator: Includes built‑in operator and potentiometer for local control and parameter adjustment.
- Cooling: Internal air‑cooling system for reliable thermal management in enclosed installations.
- Compact Form Factor: Booksize (compact) frame reduces panel footprint.
- Frame Height: Approximately 48.3 cm tall, 15.2 cm wide, and 26.7 cm deep; weight ~10.7 kg.
- KVA Rating: Design supports around 11 kVA capability suited for industrial motors.
- Legacy Support: Widely used in emerging markets, with manuals available (TM.V7.01) for configuration and installation.
The CIMR‑V7AT45P5 delivers the reliability and precision required for general-purpose industrial motor control.
