Cisco C9117AXI-B Catalyst 9117 Indoor Wi-Fi 6 Access Point With Internal Antennas and Multigigabit Ethernet
- Regular price
- $1,199.00
- Sale price
- $1,199.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: C9117AXI-B
Description
The Cisco C9117AXI-B is an indoor Wi-Fi 6 access point designed for enterprise networks with demanding wireless capacity requirements. Its eight-stream 5 GHz radio, four-stream 2.4 GHz radio, and multigigabit Ethernet connection support concurrent users in offices, classrooms, and other densely occupied spaces.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Cisco |
| Category | Networking Equipment |
| Part Number | C9117AXI-B |
| Subcategory | Wireless Access Points |
| Product Series | Catalyst 9117 |
| Wireless Standards | IEEE 802.11a/b/g/n/ac/ax; Wi-Fi 6 |
| Frequency Bands | Concurrent 2.4 GHz and 5 GHz |
| Radio Configuration | 2.4 GHz: 4×4 with four spatial streams; 5 GHz: 8×8 with eight spatial streams |
| Maximum Wireless PHY Rate | Up to 5 Gbps on 5 GHz with 802.11ax; actual throughput varies |
| Regulatory Domain | B; United States |
| Antenna Configuration | Integrated antennas; 4 dBi peak gain at 2.4 GHz and 6 dBi at 5 GHz |
| Ethernet Uplink | 1 × RJ45; 100/1000/2500/5000 Mbps |
| Additional Interfaces | RJ45 console; USB 2.0 with up to 4.5 W, subject to software and power-mode support |
| Bluetooth Radio | Integrated Bluetooth Low Energy 5.0 |
| Controller Compatibility | Catalyst 9800 Series; Cisco 3500, 5520, 8540, and Virtual Wireless Controllers with supported software |
| Power Requirements | IEEE 802.3bt/Cisco Universal Power over Ethernet for full radio operation with USB; 802.3at supports full radios with USB disabled; 802.3af provides reduced operation |
| Operating Environment | 32–122°F / 0–50°C; 10–90% relative humidity, noncondensing |
| Dimensions | 8.70 × 8.70 × 2.19 inches, width × length × height, without mounting bracket |
| Weight | 3.02 lbs |
Information About C9117AXI-B
The C9117AXI-B is a Catalyst 9117 Series access point with integrated antennas and a housing designed for ceiling or wall installation. It works with compatible Cisco wireless LAN controllers, including the Catalyst 9800 Series, subject to software release support. Downlink orthogonal frequency-division multiple access and multiuser multiple-input multiple-output technologies improve how radio resources are shared among compatible clients. The B regulatory domain identifies the model intended for United States deployments.
Key Features:
- Dual-band connectivity: Operates concurrently on the 2.4 GHz and 5 GHz bands.
- Eight-stream operation: Supports 8×8 radio operation with eight spatial streams on 5 GHz.
- Integrated antennas: Uses internal antennas with peak gains of 4 dBi at 2.4 GHz and 6 dBi at 5 GHz.
- Multigigabit uplink: Provides one Ethernet connection supporting 100 Mbps, 1 Gbps, 2.5 Gbps, and 5 Gbps.
- Wireless capacity: Supports physical-layer rates up to 5 Gbps on 5 GHz under supported configurations.
- Bluetooth connectivity: Includes a Bluetooth Low Energy 5.0 radio for location and wayfinding applications.
- Centralized management: Supports configuration and monitoring through compatible Cisco wireless controllers.
- Ethernet power: Accepts supported Power over Ethernet sources, with available radio and USB functions determined by the power mode.
The C9117AXI-B delivers the reliability and precision required for managed indoor wireless networks serving numerous concurrent devices.
