Cisco CW9166I-MR Wi-Fi 6E Enterprise Tri-Band Access Point
- Regular price
- $1,345.00
- Sale price
- $1,345.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: CW9166I-MR
Description
The Cisco CW9166I-MR is an enterprise tri-band Wi-Fi 6E access point designed for high-density wireless environments. It supports 2.4 GHz, 5 GHz, and 6 GHz Wi-Fi operation with internal omnidirectional antennas and cloud-based management through Cisco Meraki.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Cisco |
| Category | Networking |
| Part Number | CW9166I-MR |
| Subcategory | Wireless Access Point |
| Product Type | Enterprise Wi-Fi 6E Access Point |
| Wireless Standard | Wi-Fi 6E / 802.11ax |
| Wi-Fi Bands | 2.4 GHz, 5 GHz, 6 GHz |
| Ethernet Interface | 1 x 100/1000/2.5G/5G BASE-T RJ45 |
| DC Power Connector | 8 mm, center positive |
| USB Interface | USB 2.0, up to 4.5 W |
| Wi-Fi Antennas | Internal, omnidirectional in azimuth |
| 2.4 GHz Antenna Gain | 3 dBi peak |
| 5 GHz Antenna Gain | 5 dBi peak |
| 6 GHz Antenna Gain | 4 dBi peak |
| Power Source | 54V DC power jack |
| Cloud Management | Cisco Meraki Dashboard |
| Dimensions | 9.5 x 9.5 x 2.2 in. (241.3 x 241.3 x 56.9 mm) |
| Warranty | 2 Years 6 Months |
| Weight | 1.6 kg |
Information About CW9166I-MR
The CW9166I-MR is part of Cisco's Catalyst wireless access point portfolio and is designed for enterprise network deployments requiring high-capacity wireless connectivity. Its multi-band radio architecture supports Wi-Fi 6E operation across three frequency bands for dense client environments. The access point provides a 100/1000/2.5G/5G BASE-T Ethernet interface through an RJ45 connection, along with a dedicated DC power connector and USB 2.0 interface. Its internal antenna design and compact enclosure support ceiling or other suitable indoor installation configurations.
Key Features:
- Wi-Fi 6E Connectivity: Supports wireless operation across 2.4 GHz, 5 GHz, and 6 GHz bands.
- Tri-Band Radio Design: Provides simultaneous access to three Wi-Fi frequency ranges for high-density deployments.
- 5G Ethernet Interface: Supports 100 Mbps, 1 Gbps, 2.5 Gbps, and 5 Gbps BASE-T connectivity through RJ45.
- Meraki Cloud Management: Supports centralized cloud-based management through the Cisco Meraki Dashboard.
- Internal Antennas: Uses integrated omnidirectional antennas for wireless coverage.
- High-Density Application: Designed for enterprise environments with demanding wireless client requirements.
- DC Power Input: Uses a 54V DC power source through the dedicated power jack.
- USB 2.0 Interface: Provides a USB 2.0 connection with up to 4.5W power.
The CW9166I-MR delivers the reliability and precision required for high-density enterprise wireless networking applications.
