CJ1W-AD081-V1 | Omron | Expansion Module
- Regular price
- $314.00
- Sale price
- $314.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: CJ1W-AD081-V1
Description
The Omron Automation CJ1W-AD081-V1 is a PLC expansion module featuring 8 analog inputs. Designed as part of the CJ1W series, it supports a wide range of analog input signals, including -10 to 10 V, 0 to 5 V, 1 to 5 V, and 4 to 20 mA. With a resolution of 13 bits and a conversion time of 4000 ms/unit, it ensures accurate data acquisition.
This expansion module is equipped with DIN rail mount and screw terminals for easy installation and wiring. It is also RoHS-compliant, meeting environmental standards. These features make it suitable for integration into various industrial applications, including factories, robots, and automobiles.
Technical Specifications
|
Part Number |
CJ1W-AD081-V1 |
|
Manufacturer |
OMRON |
|
Category |
PLCs/Machine Control |
|
Subcategory |
PLC Module/Rack |
|
Series |
CJ1W |
|
Type |
Analog Input Module |
|
Number of Analog Inputs |
8 |
|
Input Range |
-10 to 10 V, 4-20 mA |
|
Resolution |
13 Bit |
|
I/O System |
CJ I/O Bus |
|
Expansion Unit Type |
Special I/O Unit |
|
Temperature Input Type |
None |
|
Linear Analog Input Type |
-10 to 10 V, 0 to 10 V, 0 to 5 V, 1 to 5 V, 4 to 20 mA |
|
Number of Analog Outputs |
0 |
|
I/O Connection Type |
Screw Terminals |
|
Number of I/O Connectors |
1 |
Information About CJ1W-AD081-V1
The Omron Automation CJ1W-AD081-V1 is a PLC expansion module designed for precise analog input acquisition. Featuring 8 analog input channels, this module supports a wide range of input signals, including -10 to 10 V, 0 to 5 V, 1 to 5 V, and 4 to 20 mA. This versatility allows for seamless integration into various industrial automation systems.
With its 13-bit resolution and a conversion time of 4000 ms per unit, the CJ1W-AD081-V1 ensures accurate and reliable data acquisition, making it suitable for applications where precise measurements are critical.
The module is part of the CJ1W Series and is engineered to meet demanding industrial standards. It comes equipped with a DIN rail mount and screw terminals, facilitating easy installation and maintenance in control cabinets and industrial environments.
Furthermore, the CJ1W-AD081-V1 is RoHS-compliant, adhering to environmental regulations and ensuring sustainable manufacturing practices. Its compliance with RoHS standards underscores Omron's commitment to environmental responsibility.
The CJ1W-AD081-V1's robust design and wide input signal compatibility make it an ideal choice for various industrial applications, including factories, robotics, and automotive systems. Its ability to handle diverse analog input signals enables engineers and system integrators to monitor and control critical parameters with precision and efficiency.
Manufacturer information
OMRON Corporation, founded in 1933, is a global leader in automation, sensing, and control technologies. Headquartered in Kyoto, Japan, OMRON delivers innovative solutions for industrial automation, healthcare, electronic components, and social systems, contributing to a safer, efficient, and sustainable world.
