CJ1W-OD211 | Omron Digital Output Unit, 16 x Transistor Outputs, NPN, 0.5 A, 12 to 24 VDC
- Regular price
- $239.00
- Sale price
- $239.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: CJ1W-OD211
Description
The Omron CJ1W-OD211 is a 16-point DC output module designed for use with CJ-Series PLCs. It provides transistor-based outputs rated for 12–24 VDC and up to 0.5 A per point, enabling reliable control of external loads such as indicators, solenoid valves, and small motors. The module features a removable terminal block for simplified wiring and occupies a single I/O unit slot in the CJ-Series architecture.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Omron |
| Category | Output Module |
| Part Number | CJ1W-OD211 |
| Subcategory | CJ-Series Output Unit |
| Product Type | DC Output Module |
| Number of I/O Points | 16 |
| Output Voltage Range | 12–24 VDC |
| Output Current per Point | 0.5 A |
| Common Terminals | 1 |
| External Connection | Removable terminal block |
| Occupied I/O Points | 1 |
| Current Consumption | 0.10 A max at 5 VDC |
| Supported Loads | Solenoid valves, motors, indicators |
| Terminal Type | Removable |
| Mounting Style | CJ-Series Backplane |
| Enclosure Style | Open |
Information About CJ1W-OD211
The CJ1W-OD211 is part of the Omron CJ-Series modular control platform, offering compact output interfacing for machine and process automation. With 16 transistor outputs and a single common terminal, it enables straightforward wiring for devices requiring DC switching. The module integrates seamlessly with other CJ1 units, supporting flexible system expansion while maintaining fast response times typical of solid-state output modules. Designed for applications such as actuator control, machine indicators, and small device triggering, the CJ1W-OD211 provides dependable switching performance with low power consumption of only 0.10 A at 5 VDC. Its removable terminal block facilitates efficient installation and maintenance, making it well-suited for environments requiring modular and serviceable control hardware.
Key Features:
- 16 DC Output Points: Supports a range of low-voltage industrial devices.
- 12–24 VDC Output Range: Suitable for common machine control applications.
- 0.5 A Output Capacity per Point: Drives solenoids, indicators, and small motors.
- Transistor Output Design: Provides fast switching and long operating life.
- Removable Terminal Block: Simplifies wiring and module replacement.
- Single Common Terminal: Streamlined wiring for grouped outputs.
- Low Power Consumption: Draws only 0.10 A from the 5 V bus.
- CJ-Series Compatibility: Integrates easily into Omron’s modular PLC platform.
The CJ1W-OD211 delivers the reliability and precision required for dependable DC output control in compact industrial automation systems.
