Concealite FA900-W-ELSPSTW Hidden Fire Alarm Speaker Strobe White
- Regular price
- $475.00
- Sale price
- $475.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: FA900-W-ELSPSTW
Description
The Concealite FA900-W-ELSPSTW is a concealed white speaker strobe designed for wall-mounted fire alarm notification applications. It combines audible emergency voice output with visual strobe signaling while remaining concealed behind a rotating door until the fire alarm system activates. The FA900-W-ELSPSTW uses a factory-installed Wheelock notification appliance within Concealite’s FA900 Conceal-Alarm assembly.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Concealite |
| Category | Fire Alarm Systems |
| Part Number | FA900-W-ELSPSTW |
| Subcategory | Speaker Strobes |
| Product Series | FA900 Conceal-Alarm |
| Product Type | Concealed Fire Alarm Speaker Strobe |
| Application | Wall Mount |
| Appliance Color | White |
| Notification Type | Audible and Visual |
| Speaker Function | Emergency Voice / Public Address |
| Speaker Voltage | 25 V / 70 V |
| Speaker Wattage Settings | 1/8, 1/4, 1/2, 1, 2 W |
| Wall Strobe Candela Options | 15, 30, 75, 110, 135, 185 cd |
| Conceal-Alarm Supply Voltage | 16–33 VDC or FWR |
| Conceal-Alarm Current Draw | 600 mA plus notification appliance current |
| Notification Appliance Manufacturer | Wheelock |
| Listing Standards | ETL Listed to UL 1971, UL 1480, UL 464 |
| Weight | 8 lb |
Information About FA900-W-ELSPSTW
The FA900-W-ELSPSTW is a Concealite FA900 Series concealed speaker strobe configured for white, wall-mounted installations. The assembly uses Concealite’s rotating Conceal-Alarm mechanism, which exposes the notification appliance when the fire alarm system is activated. Concealite specifies Wheelock devices for its Conceal-Alarm product line, allowing the speaker to support emergency voice or public-address communication while the strobe provides visual notification. The FA900 platform interfaces with standard fire alarm systems and supports synchronization of its visual appliance through compatible fire system synchronization modules.
Key Features:
- Concealed Notification Design: Keeps the fire alarm appliance behind a rotating door until system activation.
- Speaker Strobe Configuration: Combines emergency voice reproduction and visual strobe notification in one assembly.
- Wall-Mount Application: FA900-W configuration is specifically identified for wall-mounted installations.
- White Finish: Supplied in a white configuration for integration with light-colored architectural surfaces.
- Wheelock Appliance: Incorporates a factory-installed Wheelock fire alarm notification appliance.
- Selectable Speaker Output: Supports multiple speaker wattage settings for 25 V and 70 V audio systems.
- Selectable Candela Options: Wall strobe configurations support multiple candela settings depending on the specified appliance configuration.
- Synchronized Strobe Support: Compatible with standard fire alarm synchronization modules for coordinated visual signaling.
The FA900-W-ELSPSTW delivers the reliability and precision required for concealed emergency voice and visual fire alarm notification applications.
