CP7911-1024-0000 | Beckhoff 12" Single-touch Control Panel, IP65, DVI/USB Extended Interface
- Regular price
- $5,822.00
- Sale price
- $5,822.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: CP7911-1024-0000
Description
The Beckhoff CP7911-1024-0000 is an industrial control panel with a 12-inch TFT display, 800 × 600 resolution, and resistive single-touch operation. Built with an aluminum housing and IP65 protection, it is suited for machine and plant environments requiring durability and reliability. Its DVI/USB extended interfaces enable long-distance connectivity of up to 50 meters for flexible integration with industrial PCs.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Beckhoff Automation |
| Category | Industrial Control Panels |
| Part Number | CP7911-1024-0000 |
| Subcategory | Single-touch Control Panel |
| Device Type | Industrial Control Panel with DVI/USB Extended Interface |
| Display Size/Resolution | 12" TFT, 800 × 600 pixels |
| Touch Technology | Single-touch resistive |
| Housing Material | Aluminum housing |
| Protection Rating | IP65 housing, IP67 power connector |
| Front Panel Features | PLC buttons, F-keys, complete keyboard |
| Interfaces | DVI-E input, USB-E 2.0, 4-pin M12 power socket |
| Power Supply | 24 V DC |
| Operating Distance | Up to 50 m (DVI/USB extended) |
| Mounting Options | 75 × 75 mm drilling dimensions for arm systems |
| Dimensions | 354 mm × 326 mm × 28 mm |
| Operating Temperature | 0…55 °C |
| Custom Adaptations | Available |
| Application | Machine control, plant operation, harsh industrial environments |
| Weight | 10.41 lbs |
Information About CP7911-1024-0000
The CP7911-1024-0000 is part of the Beckhoff CP79xx series of control panels, specifically developed for industrial automation and operator interface tasks. The unit features a rugged design with IP65 protection on the housing and IP67 protection at the power connector, making it suitable for harsh environments. It includes PLC-specific function keys for direct machine control, along with DVI-E and USB-E connections that support long-distance transmission of video and data signals. With its aluminum body and slim design, the panel ensures reliable and space-efficient installation in demanding applications.
Key Features:
- Resistive single-touch technology: Accurate input for industrial operator control.
- Durable housing: Aluminum frame with IP65 front protection and IP67-rated power connector.
- 12-inch TFT display: Resolution of 800 × 600 pixels for clear visualization.
- Extended connectivity: DVI-E and USB-E inputs support distances up to 50 m.
- Programmable function keys: Includes PLC buttons and F-keys for versatile control options.
- Mounting flexibility: 75 × 75 mm drilling pattern for arm or panel mounting.
- Operating reliability: Designed for machine and plant environments with 24 V DC power supply.
- Compact dimensions: Slim profile with length 354 mm, width 326 mm, and thickness 28 mm.
The CP7911-1024-0000 delivers the reliability and accuracy required for industrial machine control and visualization tasks.
