CSR2150N | Eaton Cutler-Hammer CSR Series Standard Circuit Breaker 150A 2-Pole 120/240V 25 kAIC
- Regular price
- $205.00
- Sale price
- $205.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: CSR2150N
Description
The Eaton Cutler-Hammer CSR2150N is a standard molded case circuit breaker designed for use as a main breaker in single-phase electrical systems. This two-pole breaker is rated at 150 A and operates at 120/240 V with a thermal-magnetic trip mechanism. The CSR2150N provides reliable overload and short-circuit protection in residential and light commercial power distribution applications.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Eaton Cutler-Hammer |
| Category | Molded Case Circuit Breaker |
| Part Number | CSR2150N |
| Subcategory | Molded Case / 2-Pole |
| Series / Family | CSR Series |
| Breaker Type | CSR |
| Number of Poles | 2 |
| Amperage Rating | 150 A |
| Voltage Rating | 120/240 V |
| Phase | 1 |
| Trip Unit Type | Thermal-Magnetic |
| Protection Functions | LI – Long-Time and Instantaneous |
| Interrupt Rating | 25 kA at 240 V |
| Connection Type | Plug-In |
| Compatible Enclosure Type | ECC Unit Enclosures |
| Conductor Range | #2 AWG to 300 kcmil |
Information About CSR2150N
The CSR2150N is part of Eaton’s Cutler-Hammer CSR Series, engineered to provide dependable main circuit protection in single-phase electrical installations. It incorporates thermal and magnetic sensing elements that respond to prolonged overloads and instantaneous fault conditions. The breaker is configured as a two-pole device for 120/240 V systems commonly used in residential and light commercial service equipment. Its plug-in design allows straightforward installation and replacement within compatible ECC unit enclosures while maintaining secure electrical connections.
Key Features:
- CSR Series Standard Design: Developed for use as a main breaker in Eaton Type ECC unit enclosures.
- Thermal-Magnetic Protection: Provides long-time overload protection and instantaneous response to short-circuit conditions.
- 150 Amp Current Rating: Suitable for main and feeder circuits requiring higher current capacity.
- Two-Pole Configuration: Ensures simultaneous protection and disconnection of both ungrounded conductors.
- 25 kA Interrupting Capacity: Safely interrupts high fault currents at rated voltage levels.
- Plug-In Mounting: Simplifies installation and maintenance with reduced downtime.
- Wide Conductor Compatibility: Accepts conductors from #2 AWG to 300 kcmil to support various load requirements.
The CSR2150N delivers the reliability and precision required for effective main circuit protection in Eaton Cutler-Hammer CSR Series electrical distribution systems.
