CV2150XMM | Eaton 2-Pole 150A 240V Molded Case Circuit Breaker, 65kAIC Thermal Magnetic
- Regular price
- $299.00
- Sale price
- $299.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: CV2150XMM
Description
The Eaton CV2150XMM is a 2-pole thermal magnetic molded case circuit breaker designed for reliable motor and branch circuit protection in commercial and industrial applications. Rated for 150 amps and 240 volts, it provides long-time and instantaneous trip functions for enhanced safety and performance. This breaker ensures consistent protection against overloads and short circuits with a 65 kA interrupting capacity.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Eaton |
| Category | Circuit Protection |
| Part Number | CV2150XMM |
| Subcategory | Molded Case Circuit Breaker |
| Series | CV |
| Amperage Rating | 150 A |
| Voltage Rating | 120/240 V AC |
| Number of Poles | 2 |
| Interrupting Rating | 65 kAIC @ 240V |
| Trip Type | Thermal Magnetic (LI – Long-Time, Instantaneous) |
| Mounting Type | W Mount |
| Connection Type | Bolt-On |
| Frame Type | CV |
| Wire Range | #6–4/0 AWG Cu/Al |
| Terminal Type | Load Lugs |
| Certifications | UL 489, CSA C22.2 No. 5 |
| Applications | Motor and branch circuit protection |
| Dimensions (L × W × H) | 7.5 in × 3.5 in × 5 in |
| Warranty | Limited Lifetime |
| Weight | 2.75 lb |
Information About CV2150XMM
The CV2150XMM is part of Eaton’s CV series molded case circuit breakers, known for their robust construction and dependable protection. It features a bolt-on connection type and a thermal magnetic trip unit that combines both long-time and instantaneous protection functions (LI). Designed for use in single-phase systems, the breaker complies with UL 489 and CSA C22.2 No. 5 standards, ensuring high safety and compatibility across installations. Its compact W-mount frame allows easy integration into tenant main or panelboard applications.
Key Features:
- High Interrupting Capacity: Rated at 65 kAIC at 240V for dependable fault protection.
- Thermal Magnetic Protection: Combines long-time and instantaneous trip functions for overload and short-circuit protection.
- Compact Two-Pole Design: Suitable for space-limited enclosures and tenant main breaker panels.
- Bolt-On Connection: Ensures secure installation and reliable electrical contact.
- UL and CSA Certified: Meets UL 489 and CSA C22.2 No. 5 standards for quality and safety.
- Wide Wire Compatibility: Accepts #6–4/0 AWG copper or aluminum conductors for versatile wiring.
- Durable Construction: Built for long-term performance in demanding commercial and industrial environments.
- Accessory Ready: Supports mounting kits and additional components for extended functionality.
The CV2150XMM delivers the reliability and precision required for secure and efficient power distribution in electrical systems.
