D0-05DR-D | Automation Direct 12-24VDC PLC 8 DC Input 6 Point Relay Output AC Power Supply
- Regular price
- $315.00
- Sale price
- $315.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: D0-05DR-D
Description
The D0-05DR-D by Automation Direct is a versatile PLC with 8 DC inputs and 6 relay outputs. Powered by 12-24VDC, it includes an integrated AC power supply, making it ideal for small-scale automation projects. This unit offers robust control capabilities in a compact form, perfect for industrial applications.
Technical Specifications
| Condition | New / Never Used Surplus |
| Brand | Automation Direct |
| Category | Controls & Indicators |
| Part Number | D0-05DR-D |
| Subcategory | CPU/Control Board |
| Item | PLC |
| Series | DL05 |
| Total Memory | 6k words |
| Ladder Memory | 2k words |
| User Data Memory | 4k words |
| Programming Language | Ladder |
| Programming Software | DirectSOFT programming software v4.0 or later |
| Communication Port and Connection Type(s) | (2) RS-232 (RJ12) |
| Port Protocol(s) | DirectNET Modbus RTU K-sequence programming and monitoring |
| Port Speed(s) | fixed at 9.6k baud up to 38.4k baud |
| Real Time Clock/Calendar | No |
| Retentive Memory | No |
| Battery Backup | No |
| Maximum Expansion Modules Allowed | 1 |
| External Power Requirement | 12-24 VDC |
| Number of Discrete Input Points | 8 |
| Nominal Input Voltage | 12-24 VDC |
| Voltage Type | DC |
| Discrete Input Type | Sinking/sourcing |
| Number of Isolated Discrete Input Commons | 2 |
| Number of Points per Discrete Input Common | 4 |
| Frequency Response | 5 kHz |
| Number of Discrete Output Points | 6 |
| Nominal Output Voltage | 12-24 VDC/12-240 VAC |
| Discrete Output Type | Relay |
| Relay Configuration | (6) Form A (SPST) relays |
| Load Current | 2A/point |
| Number of Isolated Discrete Output Commons | 2 |
| Number of Points per Discrete Output Common | 3 |
| Maximum Number of PID Loops | 4 |
| Number of High-Speed Capable Input Points | 3 |
| High-Speed Counter(s) | up to (1) up counter up to (1) quadrature (A and B) counter |
| Position Scaling | up to (1) up counter up to (1) quadrature (A and B) counter |
| Frequency Measurement | up to (1) up counter up to (1) quadrature (A and B) counter |
| Interrupt(s) | up to (1) input interrupt up to (1) timer interrupt |
Information About D0-05DR-D
The D0-05DR-D is a versatile and compact PLC from Automation Direct's DL05 series, engineered to meet the demanding requirements of industrial automation systems. Designed as a CPU/control board with integrated I/O capabilities, this PLC provides an efficient and reliable solution for various control tasks in small to medium-sized applications.
This PLC features a total memory capacity of 6k words, which is divided into 2k words for ladder memory and 4k words for user data memory. The ladder memory is dedicated to storing control logic, while the user data memory is reserved for storing variables, data registers, and other user-defined information. This configuration allows for the development of complex control programs while maintaining sufficient space for user data management.
Programming the D0-05DR-D is facilitated by the DirectSOFT programming software, compatible with version 4.0 or later. This user-friendly software supports ladder logic programming, enabling users to design, test, and deploy control applications efficiently. The PLC supports standard ladder logic as its programming language, making it accessible for users familiar with this widely used control programming method.
The D0-05DR-D comes equipped with two RS-232 communication ports using RJ12 connectors. These ports support DirectNET and Modbus RTU protocols, providing flexible communication options for integration with other devices and systems. The port speeds are fixed at 9.6k baud but can be configured up to 38.4k baud, ensuring reliable data transfer and communication performance in various network configurations.
The PLC operates on an external power supply with a voltage range of 12-24 VDC, allowing it to be easily integrated into systems with different power requirements. It features 8 discrete input points and 6 discrete output points. The input points support both sinking and sourcing configurations, with a nominal input voltage of 12-24 VDC. The discrete outputs are configured as relay outputs, capable of handling both AC and DC loads, with a nominal voltage range of 12-24 VDC and 12-240 VAC. Each relay is rated to handle a load current of 2A per point, making the D0-05DR-D suitable for controlling a wide range of devices.
The PLC includes two isolated discrete input commons and two isolated discrete output commons, each with 4 and 3 points per common, respectively. This isolation enhances the system's noise immunity and ensures reliable operation in electrically noisy environments.
The D0-05DR-D is equipped with features that enhance its functionality in high-speed applications. It supports up to 4 PID loops, which can be used for precise control of process variables. Additionally, it includes high-speed capabilities with up to 3 high-speed input points, supporting up to one up counter or one quadrature (A and B) counter. These high-speed counters enable the PLC to perform position scaling, frequency measurement, and manage interrupts, with support for up to one input interrupt and one timer interrupt.
Despite its compact size, the D0-05DR-D allows for one expansion module, enabling users to extend its I/O capabilities as needed. However, it does not include a real-time clock/calendar, retentive memory, or battery backup, which may be considerations for applications requiring time-based operations or data retention during power outages.
