D2-08ND3 | Automation Direct Discrete Input Module Direct

Description

Technical Specifications

Information About D2-08ND3

The DirectLOGIC D2-08ND3 is a discrete input module designed for integration into PLC systems within industrial automation environments. Part of the DL205 series, this module is engineered to provide reliable monitoring and processing of digital signals, making it an essential component for controlling and managing various automated processes. The D2-08ND3 is specifically designed to handle 12-24 VDC input signals, making it versatile for use in a wide range of applications that require precise and dependable digital input processing.

This input module features eight discrete input points, each capable of handling both sinking and sourcing input types. This flexibility allows the D2-08ND3 to interface with various types of field devices, including sensors, switches, and other digital input components. The ability to support both sinking and sourcing inputs provides greater versatility in system design, enabling the module to be used in a variety of industrial settings where different wiring configurations may be required.

The D2-08ND3 is equipped with a single non-isolated input common, which groups all eight input points. This configuration is designed for simplicity and ease of wiring, reducing the complexity of installation and ensuring a streamlined setup process. The common input design is particularly beneficial in systems where space is at a premium and where straightforward, efficient wiring is required to minimize installation time and potential errors.

One of the key features of the D2-08ND3 is its removable terminal block. This feature allows for easy connection and disconnection of the module, facilitating quick installation and maintenance. The removable terminal block ensures that wiring changes or module replacements can be conducted without the need to disconnect and rewire the entire system, thereby minimizing downtime and enhancing operational efficiency. This design consideration is especially important in industrial environments where equipment uptime is critical and maintenance windows are limited.

Although the D2-08ND3 is not classified as a fast response module, it is still well-suited for a wide range of standard industrial applications. The module is designed to handle typical digital input signals reliably, ensuring accurate signal processing and integration into the overall control system. Its robust design and dependable performance make it a reliable choice for general-purpose digital input tasks in automation systems.

The D2-08ND3 is fully compatible with DirectLOGIC’s DirectSOFT programming software, version 4.0 or later. This compatibility ensures that the module can be easily integrated into existing DirectLOGIC systems, allowing for seamless programming and configuration. DirectSOFT software provides a user-friendly interface for programming the DL205 series modules, including the D2-08ND3, making it straightforward to set up, monitor, and troubleshoot the module within the larger PLC system.

The DirectLOGIC DL205 series, of which the D2-08ND3 is a part, is known for its reliability and ease of use in industrial automation. The series is widely used in applications ranging from manufacturing to process control, where reliable digital input processing is crucial for maintaining system performance and operational efficiency. The D2-08ND3 contributes to this reputation by offering consistent performance in monitoring and processing digital signals, ensuring that the connected PLC system operates as intended.

In terms of physical design, the D2-08ND3 is built to withstand the rigors of industrial environments. Its construction is robust, ensuring long-term durability and resistance to the typical environmental challenges found in industrial settings, such as vibration, temperature fluctuations, and electrical noise. The module’s design also takes into account the need for efficient space utilization, with its compact form factor allowing it to be easily installed in systems where space constraints are a consideration.

Overall, the DirectLOGIC D2-08ND3 discrete input module is a reliable and versatile component designed for integration into DL205 series PLC systems. Its support for both sinking and sourcing inputs, combined with its user-friendly features like the removable terminal block and compatibility with DirectSOFT programming software, make it an excellent choice for a wide range of industrial automation applications. Whether used in manufacturing, process control, or other automated systems, the D2-08ND3 provides the dependable performance and flexibility required to meet the demands of modern industrial environments.

Manufacturer information

Automation Direct is a well-established supplier of industrial automation and control products. Founded in 1994, the company offers a wide range of cost-effective, user-friendly solutions, including PLCs, HMIs, sensors, and more, catering to diverse automation needs globally.
