D2-08TD1 | Automation Direct 12-24VDC Output Module
- Regular price
- $105.00
- Sale price
- $105.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: D2-08TD1
Description
The Automation Direct D2-08TD1 is a 12-24VDC output module designed for the DL205 PLC series. It offers 8 discrete output channels, each capable of handling a wide range of DC loads, such as solenoids, relays, and indicators. The module ensures reliable control in automation applications, with built-in protection features to safeguard against overloads and short circuits, making it ideal for industrial environments.
Technical Specifications
| Condition | New / Never Used Surplus |
| Brand | Automation Direct |
| Category | PLCs/Machine Control |
| Part Number | D2-08TD1 |
| Subcategory | VDC Logic I/O Module |
| Item | Output module |
| I/O Module Type | Discrete |
| Series | DL205 |
| Number of Output Points | 8 |
| Nominal Output Voltage | 12-24 VDC |
| Discrete Output Type | Sinking |
| Number of Non-Isolated Output Commons | 1 |
| Number of Points per Common | 8 |
| Load Current | 0.3A/point, 2.4A/module |
| Fuse Type | Non-replaceable fuse |
| Includes | Removable terminal block |
| Programming Software | DirectSOFT programming software v4.0 or later |
Information About D2-08TD1
The Automation Direct D2-08TD1 is a reliable and efficient discrete output module designed for use within the DL205 series of programmable logic controllers (PLCs). As a critical component in industrial automation, this output module provides precise control over external devices, ensuring smooth and accurate operation in various applications. Its technical features are optimized to meet the demands of modern industrial environments, making it an ideal choice for engineers and technicians seeking dependable output control.
This output module is specifically designed for low-voltage DC applications, supporting a nominal output voltage range of 12-24 VDC. This voltage range is well-suited for a variety of industrial equipment, including actuators, relays, and other DC-powered devices. The D2-08TD1 is a sinking-type module, meaning it provides a path to ground when the output is activated, which is a common configuration in industrial control systems that require robust and consistent performance.
The D2-08TD1 features eight discrete output points, allowing it to control up to eight separate devices. This makes it a versatile choice for systems that require multiple outputs in a compact form factor. Each output point on the module is capable of handling a load current of up to 0.3A, with a total load capacity of 2.4A for the entire module. This current rating ensures that the module can reliably drive a wide range of devices without the risk of overload, making it suitable for various industrial automation tasks.
The module is designed with a single non-isolated output common, which supports all eight output points. This configuration simplifies wiring and reduces the complexity of the control system, making installation and maintenance more straightforward. The single common design is particularly beneficial in applications where space is limited, and a compact, efficient setup is required.
One of the notable features of the D2-08TD1 is its built-in fuse protection. While the fuse is non-replaceable, it provides an essential safeguard against overcurrent conditions that could damage the module or connected devices. This built-in protection enhances the overall reliability of the system, reducing the risk of downtime due to electrical faults. The non-replaceable nature of the fuse also simplifies the design, eliminating the need for users to replace fuses and reducing maintenance requirements.
The D2-08TD1 module includes a removable terminal block, which greatly facilitates the process of wiring and installation. The removable design allows for easier access to the terminals, making it more convenient to connect or disconnect wires as needed. This feature is particularly useful during system upgrades or maintenance, as it reduces the time and effort required to modify the wiring.
The module is fully compatible with DirectSOFT programming software version 4.0 or later, allowing users to easily integrate the D2-08TD1 into their existing automation systems. DirectSOFT provides a user-friendly interface for configuring and programming the module, enabling engineers and technicians to quickly set up and modify the output parameters to suit their specific application requirements. The software's flexibility ensures that the D2-08TD1 can be adapted to a wide range of tasks, from simple control functions to more complex automation processes.
In terms of durability and performance, the D2-08TD1 is designed to withstand the challenges of industrial environments. Its robust construction ensures reliable operation even in demanding conditions, making it a dependable choice for long-term use in factory automation, process control, and other industrial applications. The module's compact size and efficient design also contribute to its suitability for use in space-constrained settings, where every inch of panel space is valuable.
Overall, the Automation Direct D2-08TD1 discrete output module is a high-quality, versatile component that delivers reliable performance in a wide range of industrial automation applications. With its 12-24 VDC output range, eight output points, sinking-type configuration, and robust protection features, the D2-08TD1 is an excellent choice for engineers and technicians looking to enhance their PLC-based control systems. Whether used in new installations or as part of an upgrade to existing systems, the D2-08TD1 provides the reliability and functionality needed to meet the demands of today's industrial automation challenges.
