D2-08TR | Automation Direct Relay Output Module

Description

Technical Specifications

Information About D2-08TR

The D2-08TR is a versatile and robust Relay Output Module designed by Automation Direct, tailored for use within PLCs and machine control systems. This module is part of the VDC Logic I/O Module subcategory, making it a key component in the automation and control of various industrial processes. It is specifically engineered to provide reliable relay-based output control, enabling the seamless management of connected devices within a wide range of voltage environments.

Weighing just 0.71 lbs, the D2-08TR is compact yet durable, ensuring ease of installation and integration into existing control systems. Its lightweight design does not compromise on functionality or performance, making it an ideal choice for applications where space and weight considerations are important. Despite its compact form, the module is built to handle demanding industrial environments, providing consistent and reliable operation over its lifespan.

The D2-08TR features eight output points, each capable of handling a range of output voltages. These output points are designed to consume eight output points from the system, allowing for efficient utilization of available resources within the PLC or machine control setup. This design ensures that the module can manage multiple outputs simultaneously, enhancing the overall efficiency of the control system.

The module is equipped with a single common, which serves as a reference point for all the output points. This common connection simplifies the wiring process and reduces the complexity of the installation, making it easier to set up and maintain. The D2-08TR is designed with a current rating of 1A per point, with a maximum of 4A per common. This current handling capability ensures that the module can effectively manage the power requirements of the connected devices, providing reliable operation even under varying load conditions.

One of the critical safety features of the D2-08TR is its built-in 6.3 AMP fuse. This fuse is designed to protect the module and the connected devices from overcurrent conditions, ensuring that the system remains safe and operational even in the event of a fault. The fuse rating is carefully chosen to match the module's current handling capabilities, providing optimal protection without unnecessary interruptions to the system's operation.

The D2-08TR is highly versatile in terms of the voltage ranges it can handle. It supports an output voltage range of 5-30 VDC, making it suitable for low-voltage DC applications. Additionally, it can handle an output voltage range of 5-240 VAC, allowing it to be used in AC applications as well. This wide voltage range makes the D2-08TR an adaptable solution for a variety of industrial control scenarios, where different voltage levels may be required for different devices.

The module operates within a frequency range of 47-60 Hz, ensuring compatibility with the standard power frequencies used in most industrial settings. This frequency range allows the D2-08TR to be used in a variety of global applications, making it a flexible choice for multinational operations or systems that may need to operate in different regions.

Overall, the D2-08TR Relay Output Module by Automation Direct is a highly reliable and adaptable component designed for use in PLCs and machine control systems. Its compact size, robust construction, and wide range of supported voltages and frequencies make it an ideal solution for managing the outputs of various devices in industrial automation systems. The module's eight output points, single common, and 6.3 AMP fuse provide a balance of functionality, safety, and ease of use, ensuring that it can meet the demands of even the most complex control environments.

In summary, the D2-08TR is an essential module for any industrial control system that requires reliable relay output control. Its ability to handle both AC and DC voltages, coupled with its robust safety features and compact design, makes it a versatile and dependable choice for a wide range of applications. Whether used in a standalone control system or as part of a larger automation setup, the D2-08TR offers the performance and reliability needed to ensure smooth and efficient operation.
