Product Description P/N: D2-16TD1-2
Description
The D2-16TD1-2 is an Automation Direct 12-24VDC Output Module for the DL205 DirectLOGIC 205 series. It features 16 output channels, offering precise control and reliable switching for various devices in automation systems. This module ensures consistent performance, making it ideal for complex industrial applications.
Technical Specifications
| Condition | New / Never Used Surplus |
| Brand | Automation Direct |
| Category | PLCs/Machine Control |
| Part Number | D2-16TD1-2 |
| Subcategory | VDC Logic I/O Module |
| I/O Module Type | Discrete |
| Series | DL205 |
| Number of Output Points | 16 |
| Nominal Output Voltage | 12-24 VDC |
| Discrete Output Type | Sinking |
| Number of Non-Isolated Output Commons | 1 |
| Number of Points per Common | 16 |
| Load Current | 0.1A/point, 1.6A/module |
| Fuse Type | User-supplied external fuse |
| Includes | Removable terminal block |
| Programming Software | DirectSOFT programming software v4.0 or later |
Information About D2-16TD1-2
The D2-16TD1-2 is a versatile discrete output module from Automation Direct's DL205 DirectLOGIC 205 series, designed to manage critical industrial automation tasks requiring precise control and reliability. As a 12-24 VDC Output Module, it integrates seamlessly into a wide range of industrial applications, delivering robust performance that supports the control of various devices and systems. This module features 16 output points, enabling it to handle multiple control signals simultaneously, making it an ideal choice for complex automation setups.
Each output on the D2-16TD1-2 is configured as a sinking output, which means that the module controls the switching of current paths to ground. This configuration is particularly useful in industrial environments where multiple devices need to be switched in parallel without the risk of cross-talk or interference between control lines. The module's design includes one non-isolated output common, which simplifies wiring and reduces the number of connections required, further enhancing reliability and ease of installation.
The module supports a nominal output voltage of 12-24 VDC, making it compatible with a broad range of industrial devices, from solenoids to relays and actuators. Each of the 16 output points can handle a load current of 0.1A per point, with a total module capacity of 1.6A. This ensures that the D2-16TD1-2 can manage moderate loads without the need for additional components, simplifying system design and reducing costs.
To protect connected devices and maintain system integrity, the D2-16TD1-2 requires a user-supplied external fuse. This allows the user to select an appropriate fuse based on their specific application requirements, offering flexibility and ensuring that the module can be tailored to a wide range of operating conditions. The module also comes with a removable terminal block, which simplifies maintenance and troubleshooting by allowing for quick disconnection and reconnection of wiring.
The D2-16TD1-2 is fully compatible with DirectSOFT programming software, version 4.0 or later, providing users with a powerful tool for configuring and managing their automation systems. This software enables easy programming of the module's outputs, allowing for the creation of complex control logic and sequences that can be tailored to the specific needs of the application.
Operating within a temperature range of 0°C to 60°C (32°F to 140°F), the D2-16TD1-2 is built to withstand the harsh conditions often encountered in industrial environments. It also supports a storage temperature range of -20°C to 70°C (-4°F to 158°F), ensuring that the module remains reliable even when stored in less-than-ideal conditions. With a humidity range of 5% to 95% non-condensing, the module is designed to operate in environments where moisture levels fluctuate, providing consistent performance regardless of ambient humidity.
The D2-16TD1-2 is part of the broader DL205 DirectLOGIC 205 series, known for its modular design and scalability, making it suitable for both small-scale applications and large industrial systems. Its robust construction, coupled with its high-performance characteristics, makes the D2-16TD1-2 a reliable choice for industrial professionals seeking a durable and flexible output module to enhance their automation systems. Whether used in manufacturing, processing, or any other industrial setting, the D2-16TD1-2 delivers the precision and control required for efficient and effective automation.
