D2-32TD2 | Automation Direct 12-24VDC Output Module

Description

The D2-32TD2 is a 12-24VDC output module manufactured by Automation Direct. It provides 32 discrete outputs for use in industrial automation systems. The module is designed to interface with programmable logic controllers (PLCs) and supports direct current (DC) output within the specified voltage range. It is suitable for controlling various field devices in automation applications. The D2-32TD2 is built for reliable operation in environments requiring efficient control of DC-powered devices.

Technical Specifications

Information About D2-32TD2

The D2-32TD2 is a 32-point VDC logic I/O output module, designed for use in industrial automation systems. This module falls under the category of PLCs/Machine Control and is specifically engineered to interface with programmable logic controllers (PLCs) in environments that require precise and reliable control of direct current (DC) powered devices. Its functionality is centered around the control of devices that operate within a 12-24VDC voltage range, making it suitable for various industrial applications.

One of the key features of the D2-32TD2 is its sourcing output configuration. In a sourcing output module, the device supplies positive voltage to the connected load, meaning the module sources current to the output. This makes the D2-32TD2 ideal for applications where devices need to receive current directly from the output module. The module provides 32 discrete output points, allowing it to manage multiple devices simultaneously, providing flexibility in controlling a variety of field devices such as relays, solenoids, or other automation components.

The D2-32TD2 is designed with 4 isolated commons, each of which serves 8 output points. This design allows for increased isolation and separation of different signal groups, which can be critical in complex automation systems where noise reduction and signal integrity are paramount. The isolation between commons enhances the safety and reliability of the system, protecting against potential short circuits or cross-talk between different output groups. The 8-point-per-common configuration ensures that the outputs are grouped effectively, simplifying wiring and reducing the complexity of the installation process.

Each output point on the D2-32TD2 module is capable of delivering 0.1A of current. This output current per point is sufficient for controlling a wide range of DC-powered devices, particularly those used in industrial control applications. The module can handle a total of 3.2A per module, which provides the necessary power to operate multiple devices at once while ensuring that the current is distributed safely and effectively across all output points.

The module is engineered for efficient use in environments where multiple devices must be controlled concurrently, making it suitable for use in automated manufacturing, process control, material handling, and other industrial sectors. Its 32-point configuration provides scalability, allowing users to expand their control capabilities without requiring multiple modules. By consolidating control into a single module, the D2-32TD2 minimizes space requirements in the control panel and simplifies overall system design.

In terms of installation and integration, the D2-32TD2 is designed for easy mounting within standard PLC racks. Its compact form factor ensures that it can be easily added to existing systems without requiring significant alterations to the physical layout. The module’s design also allows for straightforward wiring, with clear labeling and a logical grouping of output points. This facilitates faster installation and reduces the risk of wiring errors, contributing to the module’s overall ease of use.

The D2-32TD2's voltage range of 12-24VDC provides flexibility for a wide range of devices and applications. Whether controlling small relays, indicators, or more complex automation components, the module’s voltage range ensures that it can meet the power requirements of most standard industrial devices. This flexibility allows the module to be used across various industries, from manufacturing and process control to material handling and packaging systems.

The sourcing output configuration is another significant feature, as it aligns with the standard design of many industrial control systems. Sourcing outputs are widely used in industrial automation because they provide a simple and effective way to control devices that require a positive DC supply. The sourcing nature of the outputs also allows for easy integration with commonly used devices, further enhancing the D2-32TD2’s adaptability in different system configurations.

Safety and reliability are core considerations in the design of the D2-32TD2 module. The isolated commons and the ability to handle moderate current loads ensure that the module operates safely in demanding environments. The module is designed to provide consistent performance even in harsh industrial conditions, where fluctuations in voltage or environmental factors could affect system operation. The isolation between commons reduces the risk of electrical faults, ensuring that a fault in one section of the system does not affect the performance of other groups of outputs.

In conclusion, the D2-32TD2 32-point VDC logic I/O module is a highly effective solution for controlling a wide range of DC-powered devices in industrial automation systems. Its sourcing output configuration, combined with its 12-24VDC voltage range, makes it suitable for numerous applications, while its 4 isolated commons and 8 points per common enhance safety and reliability. With 0.1A per point and a total of 3.2A per module, it provides sufficient power for multiple devices, ensuring that it meets the demands of modern industrial control systems. The module is designed for easy integration, flexible application, and reliable performance, making it an essential component in any industrial automation setup.
