D3-08TA-1 | Automation Direct 120-240VAC Output Module

Description

The D3-08TA-1 is an output module from Automation Direct, compatible with the DL305 series. It provides eight output points for controlling devices and operates with a voltage range of 120-240VAC. This module is designed to handle standard AC loads and facilitates efficient integration into various PLC-based control systems.

Technical Specifications

Information About D3-08TA-1

The D3-08TA-1 is an output module developed by Automation Direct for the DirectLOGIC DL305 series, designed to interface with PLCs and machine control systems. As a VDC Logic I/O module, it provides eight output points capable of handling standard AC loads, operating within a voltage range of 120-240 VAC. This module is engineered to deliver reliable and efficient performance in industrial automation environments, ensuring precise control of connected devices.

Weighing 1.00 lbs, the D3-08TA-1 is compact and easy to integrate into existing control systems, making it a versatile choice for various applications. Its lightweight design facilitates straightforward installation and minimizes the space required within control panels. The module's construction is intended to withstand typical industrial conditions, providing durability and long-term operational reliability.

The D3-08TA-1 output module features two isolated commons, with each common supporting four output points. This configuration allows for effective signal isolation, reducing the risk of cross-talk and ensuring stable operation of the connected devices. By providing two commons, the module enhances flexibility in system design, enabling the grouping of outputs according to specific application requirements. This design feature is particularly beneficial in complex automation setups, where different sections of the system may need to operate independently.

Each output point on the D3-08TA-1 module is rated for a current of 1A, providing sufficient capacity to control a variety of AC-powered devices. The module can handle a maximum of 3A per common, ensuring that each group of four outputs can manage higher combined loads without compromising performance. These current ratings make the D3-08TA-1 suitable for controlling devices such as solenoids, relays, and other low-power AC equipment commonly found in industrial automation.

The D3-08TA-1 includes a removable terminal block, simplifying the process of wiring and maintenance. The removable design allows for easy connection and disconnection of wiring, facilitating quick installation and reducing downtime during maintenance or module replacement. This feature is essential in industrial environments where system uptime is critical, and maintenance needs to be performed efficiently.

As part of the DirectLOGIC DL305 series, the D3-08TA-1 is compatible with other modules and components within this series, ensuring seamless integration and interoperability. This compatibility allows for scalable and modular system designs, enabling users to expand or modify their control systems as needed without significant reconfiguration. The D3-08TA-1's design aligns with the overall architecture of the DL305 series, ensuring consistent performance and reliable communication with other system components.

The module's robust design and reliable output performance make it an ideal choice for applications where precise control of AC devices is required. The D3-08TA-1's ability to handle standard AC voltages and provide multiple isolated outputs ensures that it can be used in a wide range of industrial settings, including manufacturing, process control, and automated assembly lines. Its ability to manage up to eight outputs effectively reduces the need for multiple modules, simplifying system design and reducing overall costs.

In addition to its primary function as an output module, the D3-08TA-1 may also include features that support system diagnostics and monitoring. These capabilities allow operators to monitor the status of each output point, providing real-time feedback and facilitating quick troubleshooting if issues arise. By enabling proactive maintenance and monitoring, the D3-08TA-1 helps maintain system uptime and enhances the overall reliability of the control system.

In summary, the Automation Direct D3-08TA-1 is a highly efficient and reliable output module designed for the DirectLOGIC DL305 series. With its 8-point output capability, voltage range of 120-240 VAC, isolated commons, and removable terminal block, it provides a robust solution for controlling AC-powered devices in various industrial automation applications. Its compact design, ease of installation, and compatibility with the DL305 series make it a valuable component for building flexible, scalable, and reliable control systems. The D3-08TA-1's features ensure that it can meet the demanding requirements of modern industrial environments, delivering consistent performance and supporting efficient and effective control of automated processes.
