D3-08TA-2 | Automation Direct 120-240VAC Output Module

Description

The D3-08TA-2 is an Automation Direct output module designed for 120-240VAC operations. It provides eight output channels for controlling devices in industrial automation systems. This module is suitable for applications requiring reliable high-voltage output control.

Technical Specifications

Information About D3-08TA-2

The D3-08TA-2 is a discrete output module designed for use in PLCs and machine control systems, specifically part of the DL305 series from Automation Direct. This module is categorized under PLCs/Machine Control and falls within the subcategory of VDC Logic I/O Modules. Weighing 0.99 lbs, the D3-08TA-2 output module provides reliable and efficient control of high-voltage output devices, making it a suitable choice for a variety of industrial automation applications.

The D3-08TA-2 output module features eight output channels, each capable of handling 120-240 VAC. These channels are designed to control discrete devices such as solenoids, relays, contactors, and other similar equipment that operate within the specified voltage range. By providing eight output points, the D3-08TA-2 allows for the control of multiple devices from a single module, optimizing space and reducing the need for additional hardware. This capability is essential for compact and efficient control panel designs, where space and modularity are critical considerations.

One of the key features of the D3-08TA-2 is its use of two isolated commons, with four output points assigned to each common. This isolation enhances the safety and reliability of the module by preventing electrical interference and ensuring that faults in one group of outputs do not affect the other group. The isolated commons provide a layer of protection for both the module and the connected devices, minimizing the risk of damage due to electrical surges or other faults. This design makes the D3-08TA-2 suitable for applications where maintaining signal integrity and equipment protection is paramount.

The D3-08TA-2 module is capable of handling a current rating of 1 Amp per point, with a maximum of 3 Amps per common. This current handling capability ensures that the module can support a wide range of devices, providing sufficient power to control each output without exceeding its design limits. The 1 Amp per point rating allows for the direct control of various industrial devices, while the 3 Amp per common limit ensures that the total current does not compromise the integrity of the common connection. This balance of individual point and common current ratings provides flexibility and safety in control system design.

The module is designed for easy integration into the DL305 series PLC system. It features standard connections that simplify installation and configuration, enabling quick setup and minimizing downtime. The compact design of the D3-08TA-2 allows it to fit into existing control panel layouts with ease, making it an ideal choice for both new installations and retrofitting into older systems. The use of standard mounting and connection practices ensures that technicians can quickly install and replace the module as needed, supporting efficient maintenance and system upgrades.

The D3-08TA-2 output module is built to withstand the demanding conditions often found in industrial environments. Its robust construction ensures durability and long-term reliability, even in the presence of electrical noise, temperature variations, and mechanical vibrations. This durability is critical for maintaining continuous operation and minimizing downtime, which are essential for industrial processes that require consistent and reliable performance.

As part of the DL305 series, the D3-08TA-2 is compatible with other modules and components within the series, providing a cohesive and integrated solution for control system needs. The modularity of the DL305 series allows users to expand and customize their control systems according to specific application requirements. By using the D3-08TA-2, operators can achieve efficient and scalable control solutions that meet the needs of their particular operational environment.

In addition to its technical features, the D3-08TA-2 output module is supported by comprehensive documentation and technical support. This support includes installation guides, wiring diagrams, and troubleshooting resources, ensuring that users have access to all the information necessary for successful implementation and operation. Access to technical support services helps users address any challenges that may arise, ensuring that the D3-08TA-2 operates effectively and reliably throughout its lifecycle.

In summary, the D3-08TA-2 is a versatile and reliable discrete output module designed for use in the DL305 series PLCs and machine control systems. Its eight-point output configuration, high-voltage capability, isolated commons, and robust current handling make it an ideal choice for controlling a wide range of industrial devices. The module's design prioritizes safety, reliability, and ease of integration, making it a valuable component for any control system requiring efficient and effective output management. By incorporating the D3-08TA-2, users can enhance their automation systems' performance and reliability, ensuring optimal control over their industrial processes.
