D3-08TD2 | Automation Direct 24VDC Discrete Output Module

Description

The D3-08TD2 is a 24VDC discrete output module manufactured by Automation Direct. It is designed to provide eight output points for controlling external devices in industrial automation systems. The module facilitates efficient and reliable control of 24VDC-powered equipment.

Technical Specifications

Information About D3-08TD2

The D3-08TD2 is a discrete output module designed by Automation Direct, classified under the PLCs/Machine Control category with a specific focus on VDC Logic I/O Modules. This module is engineered to provide reliable and efficient output control in industrial automation systems, making it a crucial component for applications requiring precise switching and control of external devices. Weighing 0.30 lbs, the D3-08TD2 is compact and lightweight, facilitating easy installation and integration into various PLC configurations without adding significant bulk or weight.

The D3-08TD2 features eight discrete output points, enabling the module to control up to eight external devices or processes simultaneously. This capability is essential for complex automation tasks where multiple outputs need to be managed and controlled independently. Each output point can handle a voltage range of 6-24 VDC, making the module versatile and compatible with a wide range of devices that operate within this voltage range. This versatility allows the D3-08TD2 to be used in various industrial applications, including manufacturing, process control, and building automation.

The module is designed with two commons, providing an organized and efficient way to manage the outputs. Each common can support up to eight output points, allowing for a clear and structured wiring layout. This configuration simplifies the wiring process and helps reduce potential errors during installation and maintenance. By grouping output points under common connections, the D3-08TD2 facilitates easier troubleshooting and management, enhancing the overall reliability and efficiency of the control system.

The D3-08TD2 supports an output current of up to 0.5A per point, ensuring that each output can drive a range of devices with varying current requirements. This current capacity is sufficient for most industrial applications where discrete outputs are used to control actuators, indicators, relays, and other low-power devices. The module's ability to handle 0.5A per point provides flexibility in application design, allowing engineers to select appropriate devices that match the output capabilities of the D3-08TD2.

The module is also designed to handle a maximum current of 1.8A per common, providing adequate current capacity to manage the combined load of the output points. This maximum current rating ensures that the commons can support the simultaneous operation of multiple outputs without exceeding the module's current handling capabilities. By maintaining current limits within safe operating ranges, the D3-08TD2 helps prevent overheating, overloading, and potential damage to both the module and connected devices, contributing to the longevity and safety of the control system.

The D3-08TD2’s compact design and lightweight build make it easy to integrate into existing PLC setups, whether for new installations or as part of system upgrades. Its small footprint allows it to fit within standard PLC racks and enclosures, conserving space and enabling more efficient use of available panel space. The lightweight nature of the module also facilitates handling and installation, reducing the physical effort required by technicians and minimizing the risk of installation errors.

In industrial environments where reliability and precision are critical, the D3-08TD2 discrete output module provides dependable performance. Its robust design ensures that it can operate effectively under various conditions, including exposure to electrical noise, temperature fluctuations, and other environmental challenges typical of industrial settings. The module's ability to maintain consistent performance in demanding conditions makes it a reliable choice for automation systems that require high uptime and minimal maintenance.

The D3-08TD2’s design supports easy integration and scalability, allowing users to expand their control systems as needed. The module’s compatibility with other Automation Direct PLC components ensures that it can be seamlessly integrated into broader system architectures, providing a cohesive and unified approach to automation. This compatibility makes the D3-08TD2 a valuable component for engineers and technicians seeking to build or expand robust and flexible control systems.

Overall, the Automation Direct D3-08TD2 is a high-quality, versatile discrete output module designed to enhance the functionality and efficiency of PLC systems. With its eight output points, 6-24 VDC output voltage range, and current handling capabilities, the D3-08TD2 is well-suited for a variety of industrial applications requiring precise and reliable output control. Its dual common configuration simplifies wiring and management, while its compact, lightweight design ensures easy integration into existing setups. By providing dependable output control, the D3-08TD2 contributes to optimized system performance, improved operational efficiency, and enhanced safety in industrial automation environments.

Manufacturer information

Automation Direct is a well-established supplier of industrial automation and control products. Founded in 1994, the company offers a wide range of cost-effective, user-friendly solutions, including PLCs, HMIs, sensors, and more, catering to diverse automation needs globally.
