D3-16ND2-1 | Automation Direct 24VDC Input Module

Description

Technical Specifications

Information About D3-16ND2-1

The D3-16ND2-1 is a 24VDC input module designed by Automation Direct for use in PLCs and machine control systems, specifically within the DirectLOGIC DL305 series. This input module falls under the category of PLCs/Machine Control and is classified as a VDC Logic I/O Module, highlighting its role in facilitating efficient and reliable input signal processing within industrial automation environments. With a robust design and versatile features, the D3-16ND2-1 serves as an essential component for expanding the input capabilities of DirectLOGIC DL305 PLC systems, enabling precise monitoring and control of various industrial processes.

Weighing just 0.49 lbs, the D3-16ND2-1 is lightweight and easy to handle, making installation and maintenance straightforward. Its compact form factor allows it to be seamlessly integrated into existing control panels and PLC racks, optimizing space utilization and simplifying system architecture. The module’s lightweight design also contributes to its ease of transport and storage, ensuring that it can be conveniently managed during system upgrades or expansions.

The D3-16ND2-1 features 16 input points, providing extensive input capacity for monitoring multiple signals simultaneously. This 16-point configuration is ideal for applications that require the collection and processing of numerous discrete input signals, such as status indicators, sensor feedback, and switch positions. The ability to handle multiple inputs enhances the flexibility and scalability of the control system, allowing it to adapt to a wide range of automation tasks and operational requirements.

Operating at a standard input voltage of 24 VDC, the D3-16ND2-1 is compatible with common industrial control signals. The 24 VDC input voltage is widely used in automation due to its safety, reliability, and noise immunity, making this module suitable for use in diverse industrial environments. The sourcing input type of the D3-16ND2-1 means that it is designed to receive signals from sourcing devices, providing compatibility with a variety of sensors and switches commonly used in industrial automation.

The D3-16ND2-1 is equipped with two commons, with four input points assigned to each common. This configuration allows for organized and efficient wiring, reducing the complexity of signal routing and improving the clarity of system layout. By grouping input points into commons, the module facilitates straightforward troubleshooting and maintenance, ensuring that technicians can quickly identify and address any issues that may arise.

A notable feature of the D3-16ND2-1 is its removable terminal block, which enhances the convenience of installation and maintenance. The removable terminal block allows for easy connection and disconnection of wiring, simplifying the process of module replacement or system reconfiguration. This feature minimizes downtime and reduces the effort required for system adjustments, making the D3-16ND2-1 a practical choice for dynamic industrial environments where flexibility and quick response are essential.

The D3-16ND2-1 input module is designed to integrate seamlessly with the DirectLOGIC DL305 series PLCs, ensuring compatibility and optimal performance. The DirectLOGIC DL305 series is known for its reliability and robust performance in industrial automation, and the D3-16ND2-1 complements this reputation by offering dependable input signal handling. Its integration into the DL305 series enhances the overall capability of the PLC system, providing users with the tools needed to monitor and control complex industrial processes effectively.

In summary, the Automation Direct D3-16ND2-1 is a high-quality 24VDC input module designed to expand the input capacity of DirectLOGIC DL305 PLC systems. With its 16 input points, sourcing input type, and removable terminal block, this module offers a reliable and flexible solution for monitoring discrete signals in various industrial automation applications. Its lightweight design, compatibility with standard industrial voltages, and efficient wiring configuration make it a valuable component for optimizing control system performance and ensuring accurate, real-time monitoring of industrial processes.

Manufacturer information

Automation Direct is a well-established supplier of industrial automation and control products. Founded in 1994, the company offers a wide range of cost-effective, user-friendly solutions, including PLCs, HMIs, sensors, and more, catering to diverse automation needs globally.
